BPI-R4 build instruction

Controller

Build
repo init -u https://code.rdkcentral.com/r/manifests -b kirkstone -m rdkb-bpi-extsrc.xml
repo sync -j`nproc` --no-clone-bundle

# Default build with AL_SAP
MACHINE=bananapi4-rdk-broadband FEATURE_TYPE=EasyMesh  source meta-cmf-bananapi/setup-environment-refboard-rdkb

#to CP the below change for fynecli access for utopia component
https://github.com/rdkcentral/utopia/pull/47

bitbake rdk-generic-broadband-image

Extender

Ext Build Instructions
repo init -u https://code.rdkcentral.com/r/manifests -b kirkstone -m rdkb-bpi-ap-extsrc.xml
repo sync -j4 --no-clone-bundle

#Default build with AL_SAP
MACHINE=bananapi4-rdk-broadband-ap-extender  source meta-cmf-bananapi/setup-environment-refboard-rdkb

bitbake rdk-generic-ap-extender-image

Flashing instructions(SD card)

flashing prodecure
Copy *.wic.bz2 from build machine (image path is ~/build-bananapi4-rdk-broadband/tmp/deploy/images/bananapi4-rdk-broadband/)

bzip2 -d <Path to ImageName.wic.bz2>
sudo -E bmaptool copy --nobmap <Path to ImageName.wic> <Path to SD card device file>


Commands to change the power level of the device

Commands to change the power level of the device
# offsets are from linux-mt76/3.x-r0/git/mt7996/eeprom.h
# copy eeprom (efuse?) into factory partition
dd if=/sys/kernel/debug/ieee80211/phy0/mt76/eeprom of=/dev/mtdblock3
# overwrite tx power limit for 2g and 5g
printf '\x29' | dd of=/dev/mtdblock3 bs=1 count=1 conv=notrunc seek=$((0x1300))
printf '\x27' | dd of=/dev/mtdblock3 bs=1 count=1 conv=notrunc seek=$((0x1301))
# reboot device
reboot
# verify eeprom_mode and tx power limits

Test EM on BPI R4

BPI Controller

Please ensure below processes are running in ctrl.

process_status
root@Filogic-GW:~# systemctl status ieee1905_em_ctrl
● ieee1905_em_ctrl.service - ieee1905 EasyMesh Controller service
     Loaded: loaded (/lib/systemd/system/ieee1905_em_ctrl.service; enabled; vendor preset: enabled)
     Active: active (running) since Thu 2022-04-28 17:43:33 UTC; 3 years 3 months ago
    Process: 4793 ExecStartPre=/bin/sh -c sleep 5 (code=exited, status=0/SUCCESS)
    Process: 4941 ExecStartPre=/bin/sh -c if [ ! -e "/sys/class/net/eth0_virt_peer/address" ]; then `/usr/ccsp/EasyMesh/setup_veth_for_em.sh brlan0 eth0 true`; fi (code=exited, status=0/SUCCESS)
    Process: 4942 ExecStart=/bin/sh -c /usr/bin/ieee1905 -f ieee1905::al_sap=trace,ieee1905::cmdu_handler=trace,ieee1905::cmdu_proxy=trace,ieee1905::cmdu_observer=trace -i eth0_virt_peer --sap-data-path /tmp/al_em_ctrl_data_socket --sap-control-path /tmp/al_em_ctrl_control_socket >> /tmp/ieee1905_ctrl_log.txt & (code=exited, status=0/SUCCESS)
   Main PID: 4943 (ieee1905)
      Tasks: 7 (limit: 4713)
     Memory: 22.3M
     CGroup: /system.slice/ieee1905_em_ctrl.service
             └─ 4943 /usr/bin/ieee1905 -f ieee1905::al_sap=trace,ieee1905::cmdu_handler=trace,ieee1905::cmdu_proxy=trace,ieee1905::cmdu_observer=trace -i eth0_virt_peer --sap-data-path /tmp/al_em_ctrl_data_socket --sap-control-path /tmp/al_em_ctrl_control_socket

Notice: journal has been rotated since unit was started, output may be incomplete.


root@Filogic-GW:~# systemctl status em_ctrl
● em_ctrl.service - EasyMesh Controller service
     Loaded: loaded (/lib/systemd/system/em_ctrl.service; enabled; vendor preset: enabled)
     Active: active (running) since Thu 2025-08-07 05:54:27 UTC; 20min ago
    Process: 18033 ExecStartPre=/bin/sh -c /usr/ccsp/EasyMesh/setup_mysql_db_pre.sh (code=exited, status=0/SUCCESS)
    Process: 18038 ExecStart=/bin/sh -c /usr/bin/onewifi_em_ctrl bpi\@root >> /tmp/em_ctrl.log & (code=exited, status=0/SUCCESS)
    Process: 18040 ExecStartPost=/bin/sh -c /usr/ccsp/EasyMesh/setup_mysql_db_post.sh (code=exited, status=0/SUCCESS)
   Main PID: 18039 (onewifi_em_ctrl)
      Tasks: 15 (limit: 4713)
     Memory: 185.2M
     CGroup: /system.slice/em_ctrl.service
             └─ 18039 /usr/bin/onewifi_em_ctrl bpi@root

Notice: journal has been rotated since unit was started, output may be incomplete.
root@Filogic-GW:~#

root@Filogic-GW:~# systemctl status ieee1905_em_agent
● ieee1905_em_agent.service - ieee1905 EasyMesh Agent service
     Loaded: loaded (/lib/systemd/system/ieee1905_em_agent.service; enabled; vendor preset: enabled)
     Active: active (running) since Thu 2025-08-07 05:54:31 UTC; 21min ago
    Process: 4944 ExecStartPre=/bin/sh -c if [ ! -e "/sys/class/net/eth1_virt_peer/address" ]; then `/usr/ccsp/EasyMesh/setup_veth_for_em.sh brlan0 eth1 false`;fi (code=exited, status=0/SUCCESS)
    Process: 4945 ExecStartPre=/bin/sh -c while [ ! -e /tmp/wifi_initialized ] && [ ! -e /tmp/wifi_dml_complete ] ;do sleep 1; done  (code=exited, status=0/SUCCESS)
    Process: 17690 ExecStartPre=/bin/sh -c sleep 5 (code=exited, status=0/SUCCESS)
    Process: 19496 ExecStart=/bin/sh -c /usr/bin/ieee1905 -f ieee1905::al_sap=trace,ieee1905::cmdu_handler=trace,ieee1905::cmdu_proxy=trace,ieee1905::cmdu_observer=trace -i eth1_virt_peer >> /tmp/ieee1905_agent_log.txt & (code=exited, status=0/SUCCESS)
   Main PID: 19497 (ieee1905)
      Tasks: 7 (limit: 4713)
     Memory: 18.8M
     CGroup: /system.slice/ieee1905_em_agent.service
             └─ 19497 /usr/bin/ieee1905 -f ieee1905::al_sap=trace,ieee1905::cmdu_handler=trace,ieee1905::cmdu_proxy=trace,ieee1905::cmdu_observer=trace -i eth1_virt_peer

Notice: journal has been rotated since unit was started, output may be incomplete.

root@Filogic-GW:~# systemctl status em_agent
● em_agent.service - EasyMesh Agent service
     Loaded: loaded (/lib/systemd/system/em_agent.service; enabled; vendor preset: enabled)
     Active: active (running) since Thu 2025-08-07 06:15:40 UTC; 17s ago
    Process: 476399 ExecStartPre=/bin/sh -c /usr/ccsp/EasyMesh/setup_agent_pre.sh (code=exited, status=0/SUCCESS)
    Process: 476405 ExecStartPre=/bin/sh -c sleep 15 (code=exited, status=0/SUCCESS)
    Process: 482087 ExecStart=/bin/sh -c /usr/bin/onewifi_em_agent >> /tmp/em_agent.log & (code=exited, status=0/SUCCESS)
   Main PID: 482089 (onewifi_em_agen)
      Tasks: 8 (limit: 4713)
     Memory: 8.8M
     CGroup: /system.slice/em_agent.service
             └─ 482089 /usr/bin/onewifi_em_agent

2025 Aug 07 06:15:25 Filogic-GW systemd[1]: Starting EasyMesh Agent service...
2025 Aug 07 06:15:40 Filogic-GW systemd[1]: Started EasyMesh Agent service.

To run cli,

cd /usr/ccsp/EasyMesh
onewifi_em_cli bpi

Observation in EM-Controller device side:

  • All configured VAPs should be UP and Running
  • VAPs should be broadcasting EasyMesh default SSIDs(eg, private_ssid, mesh_backhaul)
  • Logs files are generated under /tmp folder

Extender 1 + STAR Topology

1.Please ensure below processes are running in Ext1

process_status
root@Filogic-GW:~# systemctl status onewifi
* onewifi.service - Cosa service
     Loaded: loaded (8;;file://Filogic-GW/lib/systemd/system/onewifi.service/lib/systemd/system/onewifi.service8;;; enabled; vendor preset: e)
     Active: active (running) since Thu 2022-04-28 17:43:15 UTC; 3min 29s ago
TriggeredBy: * filogicwifiinitialized.path
    Process: 1781 ExecStartPre=/bin/sh /usr/ccsp/wifi/onewifi_pre_start.sh (code=exited, status=0/SUCCESS)
    Process: 2085 ExecStart=/usr/bin/OneWifi -subsys $Subsys (code=exited, status=0/SUCCESS)
   Main PID: 2086 (OneWifi)
      Tasks: 14 (limit: 4713)
     Memory: 38.2M
     CGroup: /system.slice/onewifi.service
             `- 2086 /usr/bin/OneWifi -subsys eRT.

2022 Apr 28 17:42:48 Filogic-GW systemd[1]: Starting Cosa service...
2022 Apr 28 17:42:53 Filogic-GW UTOPIA[2086]: system.syscfg Shared memory file not found
2022 Apr 28 17:42:53 Filogic-GW UTOPIA[2086]: 2022-04-28  17:42:53., ../../../../git/source/syscfg/lib/syscfg_lib.c:466, Error initializing sy
2022 Apr 28 17:43:15 Filogic-GW systemd[1]: Started Cosa service.
2022 Apr 28 17:44:01 Filogic-GW [OneWifi][2086]:   WiFi radio radio1 is set to UP

root@Filogic-GW:~# systemctl status ieee1905_em_agent
* ieee1905_em_agent.service - ieee1905 EasyMesh Remote Agent service
     Loaded: loaded (8;;file://Filogic-GW/lib/systemd/system/ieee1905_em_agent.service/lib/systemd/system/ieee1905_em_agent.service8;;; enabl)
     Active: active (running) since Thu 2022-04-28 17:43:35 UTC; 3min 16s ago
    Process: 3284 ExecStartPre=/bin/sh -c /usr/ccsp/EasyMesh/setup_ext_pre.sh (code=exited, status=0/SUCCESS)
    Process: 3303 ExecStartPre=/bin/sh -c if [ ! -e "/sys/class/net/eth1_virt_peer/address" ]; then `/usr/ccsp/EasyMesh/setup_veth_for_em.sh )
    Process: 3304 ExecStartPre=/bin/sh -c sleep 5 (code=exited, status=0/SUCCESS)
    Process: 3439 ExecStart=/bin/sh -c /usr/bin/ieee1905 -f ieee1905::al_sap=trace,ieee1905::cmdu_handler=trace,ieee1905::cmdu_proxy=trace,ie)
   Main PID: 3440 (ieee1905)
      Tasks: 7 (limit: 4713)
     Memory: 10.5M
     CGroup: /system.slice/ieee1905_em_agent.service
             `- 3440 /usr/bin/ieee1905 -f ieee1905::al_sap=trace,ieee1905::cmdu_handler=trace,ieee1905::cmdu_proxy=trace,ieee1905::cmdu_obserr

2022 Apr 28 17:43:30 Filogic-GW systemd[1]: Starting ieee1905 EasyMesh Remote Agent service...
2022 Apr 28 17:43:35 Filogic-GW systemd[1]: Started ieee1905 EasyMesh Remote Agent service.

root@Filogic-GW:~# systemctl status em_agent
* em_agent.service - EasyMesh Agent service
     Loaded: loaded (8;;file://Filogic-GW/lib/systemd/system/em_agent.service/lib/systemd/system/em_agent.service8;;; enabled; vendor preset:)
     Active: active (running) since Thu 2022-04-28 17:44:00 UTC; 2min 57s ago
    Process: 3283 ExecStartPre=/bin/sh -c sleep 30 (code=exited, status=0/SUCCESS)
    Process: 3621 ExecStartPre=/bin/sh -c /usr/ccsp/EasyMesh/setup_ext_pre.sh (code=exited, status=0/SUCCESS)
    Process: 3640 ExecStart=/bin/sh -c /usr/bin/onewifi_em_agent >> /tmp/em_agent.log & (code=exited, status=0/SUCCESS)
   Main PID: 3641 (onewifi_em_agen)
      Tasks: 9 (limit: 4713)
     Memory: 10.8M
     CGroup: /system.slice/em_agent.service
             `- 3641 /usr/bin/onewifi_em_agent

2.Ensure mesh backhaul connectivity is established over 5G through wifi1.1 interface.

iw dev wifi1.3 info

3.Verify mesh backhaul connection in EM-Contrller side as well.

iw dev wifi1.1.sta<i> info
iw dev wifi1.1.sta<i> station dump ## This command gives information on connected client ie Extender1.

4. Wait for few minutes( for Agent to propagate SSID information from Controller to OneWifi in Extender1) and then check

  • Check all configured VAPs should be up and running with "iw dev" command
  • VAPs should be broadcasting default EasyMesh SSIDS (ie private_ssid, mesh_backhaul)
  • logs files are generated under /tmp folder

5. Test the connectivity to EM-Controller through backhaul

ping 10.0.0.1 -c 5

Test the connectivity with wireless clients.

Extender2 (For Daisy-Chain )

1. Ensure Extender 1 is running properly with configured vap's of FH and BH.

2. Make atleast 7 feet distance from Ext1 to Ext2

3. Ensure  ieee1905_em_agent,onewifi_em_agent processes are running in Ext2

4. Ensure mesh backhaul connectivity is established over 5G through wifi1.1 interface.

iw dev wifi1.3 info

5. Verify mesh backhaul connection in Extender1 side as well.

iw dev wifi1.1.sta<i> info
iw dev wifi1.1.sta<i> station dump ## This command gives information on connected client ie Extender2.

6. Wait for few minutes( for Agent to propagate SSID information from Controller to OneWifi in Extender2) and then check

  • Check all configured VAPs should be up and running with "iw dev" command
  • VAPs should be broadcasting default EasyMesh SSIDS (ie private_ssid, mesh_backhaul)

7. Test the connectivity to EM-Controller through backhaul

ping 10.0.0.1 -c 5

Test the connectivity with wireless clients.


Sample logs

EM-Controller and EM-Agent success logs


em_ctrl logs
root@Filogic-GW:~# cat /tmp/em_ctrl.log
[onewifi_em_ctrl] 09/16/2025 - 05:37:30.251313 :em_ctrl.cpp:915: INFO: AL SAP registration successful, AL MAC: 02:01:00:ec:07:9e
[onewifi_em_ctrl] 09/16/2025 - 05:38:09.875186 :em_ctrl.cpp:915: INFO: AL SAP registration successful, AL MAC: 02:01:00:ec:07:9e
connect:170: user:bpi pass:root
create_data_model:1524: Created data model for net_id: OneWifiMesh mac: 02:01:00:ec:07:9e, coloc:1
create_data_model:1544: Number of policies: 8
create_data_model:1561: Putting data model at key: OneWifiMesh@02:01:00:ec:07:9e
create_node:203 key value used:02:01:00:ec:07:9e_al
EC Manager created with MAC: 02:01:00:ec:07:9e
[onewifi_em_ctrl] 09/16/2025 - 05:38:10.016219 :ec_1905_encrypt_layer.cpp:557: INFO: Initialized 1905 layer encryption with security parameters
em_func:558 Thread stack size = 8388608 bytes
create_node:224: created entry for key:02:01:00:ec:07:9e_al
mgr_input_listen:290 Thread stack size = 8388608 bytes
mgr_nodes_listen:436 Thread stack size = 8388608 bytes
start_complete:861 Collocated agent ID: 02:01:00:ec:07:9e publish  fail
[onewifi_em_ctrl] 09/16/2025 - 05:38:10.532520 :dm_easy_mesh_ctrl.cpp:2027: INFO: Root topology dev_mac:02:01:00:ec:07:9e, num_bss:0
update_tables:1801: Op Class[0] ruid: 02:01:00:ec:07:9e	Type: 7	Class: 81
update_tables:1801: Op Class[1] ruid: 02:01:00:ec:07:9e	Type: 7	Class: 115
update_tables:1801: Op Class[2] ruid: 02:01:00:ec:07:9e	Type: 7	Class: 135
update_tables:1801: Op Class[3] ruid: 02:01:00:ec:07:9e	Type: 8	Class: 81
update_tables:1801: Op Class[4] ruid: 02:01:00:ec:07:9e	Type: 8	Class: 115
update_tables:1801: Op Class[5] ruid: 02:01:00:ec:07:9e	Type: 8	Class: 135
analyze_config_renew:98: Radio: 00:00:00:00:00:00
find_em_for_msg_type:611: Received autoconfig search from agenti al mac: 02:01:00:ec:07:ae
create_data_model:1524: Created data model for net_id: OneWifiMesh mac: 02:01:00:ec:07:ae, coloc:0
create_data_model:1544: Number of policies: 8
create_data_model:1561: Putting data model at key: OneWifiMesh@02:01:00:ec:07:ae
find_em_for_msg_type:617: Created data model for mac: 02:01:00:ec:07:ae net: OneWifiMesh
handle_autoconfig_search:5011: autoconfig rsp send success
find_em_for_msg_type:611: Received autoconfig search from agenti al mac: 02:01:00:ec:07:ae
find_em_for_msg_type:620: Found existing data model for mac: 02:01:00:ec:07:ae net: OneWifiMesh
handle_autoconfig_search:5011: autoconfig rsp send success
find_em_for_msg_type:647: Found data model for mac: 02:01:00:ec:07:ae, creating node for ruid: 02:02:10:ec:07:92
create_node:203 key value used:02:02:10:ec:07:92
em_func:558 Thread stack size = 8388608 bytes
create_node:224: created entry for key:02:02:10:ec:07:92
process_msg:5084: received wsc_m1 len:559
handle_autoconfig_wsc_m1:4851: Device AL MAC: 02:01:00:ec:07:ae
handle_ap_radio_basic_cap:4785: Radio does not exist, getting radio at index: 0
find_em_for_msg_type:647: Found data model for mac: 02:01:00:ec:07:ae, creating node for ruid: 02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:15.995020 :em_configuration.cpp:3603: INFO: Recieved AKMs: (0x0000)

handle_wsc_m1:3647 Freq band = 0
create_node:203 key value used:02:02:20:ec:07:93
em_func:558 Thread stack size = 8388608 bytes
create_node:224: created entry for key:02:02:20:ec:07:93
process_msg:5084: received wsc_m1 len:664
handle_autoconfig_wsc_m1:4851: Device AL MAC: 02:01:00:ec:07:ae
handle_ap_radio_basic_cap:4785: Radio does not exist, getting radio at index: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:16.007897 :em_configuration.cpp:3603: INFO: Recieved AKMs: (0x0000)

handle_wsc_m1:3647 Freq band = 1
create_encrypted_settings:4591 No of haultype=4 radio no of bss=4
create_encrypted_settings:4613: ssid: private_ssid, passphrase: test-fronthaul
create_encrypted_settings:4613: ssid: mesh_backhaul, passphrase: test-backhaul
create_encrypted_settings:4613: ssid: iot_ssid, passphrase: test-backhaul
create_encrypted_settings:4613: ssid: lnf_radius, passphrase: test-backhaul
handle_autoconfig_wsc_m1:4890: autoconfig wsc m2 send, len:1036
analyze_m2_tx:223: Radio: 02:02:10:ec:07:92 AL MAC: 02:01:00:ec:07:ae
create_encrypted_settings:4591 No of haultype=4 radio no of bss=4
create_encrypted_settings:4613: ssid: private_ssid, passphrase: test-fronthaul
create_encrypted_settings:4613: ssid: mesh_backhaul, passphrase: test-backhaul
create_encrypted_settings:4613: ssid: iot_ssid, passphrase: test-backhaul
create_encrypted_settings:4613: ssid: lnf_radius, passphrase: test-backhaul
handle_autoconfig_wsc_m1:4890: autoconfig wsc m2 send, len:1036
analyze_m2_tx:223: Radio: 02:02:20:ec:07:93 AL MAC: 02:01:00:ec:07:ae
put_device:234: Device:02:01:00:ec:07:ae inserted in network:OneWifiMesh
create_node:203 key value used:02:02:10:ec:07:92
create_node:208: node with key:02:02:10:ec:07:92 already exists
put_radio:357 Node created successfully
create_node:203 key value used:02:02:20:ec:07:93
create_node:208: node with key:02:02:20:ec:07:93 already exists
put_radio:357 Node created successfully
update_tables:1779: Op Class[0] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 81	Class: 81
update_tables:1779: Op Class[1] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 115	Class: 115
update_tables:1779: Op Class[2] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 135	Class: 135
update_tables:1779: Op Class[3] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 81	Class: 81
update_tables:1779: Op Class[4] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 115	Class: 115
update_tables:1779: Op Class[5] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 135	Class: 135
update_tables:1779: Op Class[6] ruid: 02:02:10:ec:07:92	Type: 2	Class: 81	Class: 81
update_tables:1779: Op Class[7] ruid: 02:02:10:ec:07:92	Type: 2	Class: 83	Class: 83
update_tables:1779: Op Class[8] ruid: 02:02:10:ec:07:92	Type: 2	Class: 84	Class: 84
update_tables:1779: Op Class[9] ruid: 02:02:20:ec:07:93	Type: 2	Class: 115	Class: 115
update_tables:1779: Op Class[10] ruid: 02:02:20:ec:07:93	Type: 2	Class: 116	Class: 116
update_tables:1779: Op Class[11] ruid: 02:02:20:ec:07:93	Type: 2	Class: 117	Class: 117
update_tables:1779: Op Class[12] ruid: 02:02:20:ec:07:93	Type: 2	Class: 118	Class: 118
update_tables:1779: Op Class[13] ruid: 02:02:20:ec:07:93	Type: 2	Class: 119	Class: 119
update_tables:1779: Op Class[14] ruid: 02:02:20:ec:07:93	Type: 2	Class: 120	Class: 120
update_tables:1779: Op Class[15] ruid: 02:02:20:ec:07:93	Type: 2	Class: 121	Class: 121
update_tables:1779: Op Class[16] ruid: 02:02:20:ec:07:93	Type: 2	Class: 122	Class: 122
update_tables:1779: Op Class[17] ruid: 02:02:20:ec:07:93	Type: 2	Class: 123	Class: 123
update_tables:1779: Op Class[18] ruid: 02:02:20:ec:07:93	Type: 2	Class: 124	Class: 124
update_tables:1779: Op Class[19] ruid: 02:02:20:ec:07:93	Type: 2	Class: 125	Class: 125
update_tables:1779: Op Class[20] ruid: 02:02:20:ec:07:93	Type: 2	Class: 126	Class: 126
update_tables:1779: Op Class[21] ruid: 02:02:20:ec:07:93	Type: 2	Class: 127	Class: 127
update_tables:1779: Op Class[22] ruid: 02:02:20:ec:07:93	Type: 2	Class: 128	Class: 128
update_tables:1779: Op Class[23] ruid: 02:02:20:ec:07:93	Type: 2	Class: 129	Class: 129
update_tables:1779: Op Class[24] ruid: 02:02:20:ec:07:93	Type: 2	Class: 130	Class: 130

orch_execute:151: dm_orch_type_topo_sync(em_cmd_type_em_config) state: em_state_ctrl_wsc_m2_sent
find_em_for_msg_type:611: Received autoconfig search from agenti al mac: 02:01:00:ec:07:ae
find_em_for_msg_type:620: Found existing data model for mac: 02:01:00:ec:07:ae net: OneWifiMesh
handle_autoconfig_search:5011: autoconfig rsp send success
find_em_for_msg_type:647: Found data model for mac: 02:01:00:ec:07:ae, creating node for ruid: 02:02:30:ec:07:94
create_node:203 key value used:02:02:30:ec:07:94
em_func:558 Thread stack size = 8388608 bytes
create_node:224: created entry for key:02:02:30:ec:07:94
process_msg:5084: received wsc_m1 len:565
handle_autoconfig_wsc_m1:4851: Device AL MAC: 02:01:00:ec:07:ae
handle_ap_radio_basic_cap:4785: Radio does not exist, getting radio at index: 2
[onewifi_em_ctrl] 09/16/2025 - 05:38:17.015314 :em_configuration.cpp:3603: INFO: Recieved AKMs: (0x0000)

handle_wsc_m1:3647 Freq band = 2
[onewifi_em_ctrl] 09/16/2025 - 05:38:17.032091 :em_configuration.cpp:373: INFO: Topology Query (1) Sent for radio:02:02:10:ec:07:92
[onewifi_em_ctrl] 09/16/2025 - 05:38:17.032254 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
create_encrypted_settings:4591 No of haultype=1 radio no of bss=1
create_encrypted_settings:4613: ssid: private_ssid, passphrase: test-fronthaul
handle_autoconfig_wsc_m1:4890: autoconfig wsc m2 send, len:764
analyze_m2_tx:223: Radio: 02:02:30:ec:07:94 AL MAC: 02:01:00:ec:07:ae
get_dm_orch_type:127: Device: 02:02:10:ec:07:92 already in list
get_dm_orch_type:127: Device: 02:02:20:ec:07:93 already in list
create_node:203 key value used:02:02:30:ec:07:94
create_node:208: node with key:02:02:30:ec:07:94 already exists
put_radio:357 Node created successfully
update_tables:1779: Op Class[0] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 81	Class: 81
update_tables:1779: Op Class[1] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 115	Class: 115
update_tables:1779: Op Class[2] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 135	Class: 135
update_tables:1779: Op Class[3] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 81	Class: 81
update_tables:1779: Op Class[4] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 115	Class: 115
update_tables:1779: Op Class[5] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 135	Class: 135
update_tables:1779: Op Class[6] ruid: 02:02:10:ec:07:92	Type: 2	Class: 81	Class: 81
update_tables:1779: Op Class[7] ruid: 02:02:10:ec:07:92	Type: 2	Class: 83	Class: 83
update_tables:1779: Op Class[8] ruid: 02:02:10:ec:07:92	Type: 2	Class: 84	Class: 84
update_tables:1779: Op Class[9] ruid: 02:02:20:ec:07:93	Type: 2	Class: 115	Class: 115
update_tables:1779: Op Class[10] ruid: 02:02:20:ec:07:93	Type: 2	Class: 116	Class: 116
update_tables:1779: Op Class[11] ruid: 02:02:20:ec:07:93	Type: 2	Class: 117	Class: 117
update_tables:1779: Op Class[12] ruid: 02:02:20:ec:07:93	Type: 2	Class: 118	Class: 118
update_tables:1779: Op Class[13] ruid: 02:02:20:ec:07:93	Type: 2	Class: 119	Class: 119
update_tables:1779: Op Class[14] ruid: 02:02:20:ec:07:93	Type: 2	Class: 120	Class: 120
update_tables:1779: Op Class[15] ruid: 02:02:20:ec:07:93	Type: 2	Class: 121	Class: 121
update_tables:1779: Op Class[16] ruid: 02:02:20:ec:07:93	Type: 2	Class: 122	Class: 122
update_tables:1779: Op Class[17] ruid: 02:02:20:ec:07:93	Type: 2	Class: 123	Class: 123
update_tables:1779: Op Class[18] ruid: 02:02:20:ec:07:93	Type: 2	Class: 124	Class: 124
update_tables:1779: Op Class[19] ruid: 02:02:20:ec:07:93	Type: 2	Class: 125	Class: 125
update_tables:1779: Op Class[20] ruid: 02:02:20:ec:07:93	Type: 2	Class: 126	Class: 126
update_tables:1779: Op Class[21] ruid: 02:02:20:ec:07:93	Type: 2	Class: 127	Class: 127
update_tables:1779: Op Class[22] ruid: 02:02:20:ec:07:93	Type: 2	Class: 128	Class: 128
update_tables:1779: Op Class[23] ruid: 02:02:20:ec:07:93	Type: 2	Class: 129	Class: 129
update_tables:1779: Op Class[24] ruid: 02:02:20:ec:07:93	Type: 2	Class: 130	Class: 130
update_tables:1779: Op Class[25] ruid: 02:02:30:ec:07:94	Type: 2	Class: 131	Class: 131
update_tables:1779: Op Class[26] ruid: 02:02:30:ec:07:94	Type: 2	Class: 132	Class: 132
update_tables:1779: Op Class[27] ruid: 02:02:30:ec:07:94	Type: 2	Class: 133	Class: 133
update_tables:1779: Op Class[28] ruid: 02:02:30:ec:07:94	Type: 2	Class: 134	Class: 134
update_tables:1779: Op Class[29] ruid: 02:02:30:ec:07:94	Type: 2	Class: 135	Class: 135
update_tables:1779: Op Class[30] ruid: 02:02:30:ec:07:94	Type: 2	Class: 136	Class: 136

orch_execute:151: dm_orch_type_topo_sync(em_cmd_type_em_config) state: em_state_ctrl_wsc_m2_sent
[onewifi_em_ctrl] 09/16/2025 - 05:38:18.032590 :em_configuration.cpp:373: INFO: Topology Query (2) Sent for radio:02:02:10:ec:07:92
[onewifi_em_ctrl] 09/16/2025 - 05:38:18.032694 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:18.036094 :em_configuration.cpp:373: INFO: Topology Query (1) Sent for radio:02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:18.036207 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
orch_execute:151: dm_orch_type_topo_sync(em_cmd_type_em_config) state: em_state_ctrl_wsc_m2_sent
[onewifi_em_ctrl] 09/16/2025 - 05:38:19.032991 :em_configuration.cpp:373: INFO: Topology Query (3) Sent for radio:02:02:10:ec:07:92
[onewifi_em_ctrl] 09/16/2025 - 05:38:19.033097 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:19.036490 :em_configuration.cpp:373: INFO: Topology Query (2) Sent for radio:02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:19.036588 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:19.039956 :em_configuration.cpp:373: INFO: Topology Query (1) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:19.040068 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:20.033373 :em_configuration.cpp:373: INFO: Topology Query (4) Sent for radio:02:02:10:ec:07:92
[onewifi_em_ctrl] 09/16/2025 - 05:38:20.033464 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:20.036894 :em_configuration.cpp:373: INFO: Topology Query (3) Sent for radio:02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:20.036975 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:20.040350 :em_configuration.cpp:373: INFO: Topology Query (2) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:20.040439 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.033776 :em_configuration.cpp:373: INFO: Topology Query (5) Sent for radio:02:02:10:ec:07:92
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.033877 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.037314 :em_configuration.cpp:373: INFO: Topology Query (4) Sent for radio:02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.037418 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.040748 :em_configuration.cpp:373: INFO: Topology Query (3) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.040832 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.042786 :em_configuration.cpp:835: INFO: Number of radios: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.042868 :em_configuration.cpp:838: INFO: Radio: 02:02:10:ec:07:92
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.042912 :em_configuration.cpp:840: INFO: Number of bss: 3
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.042943 :em_configuration.cpp:843: INFO: BSSID=02:02:10:ec:07:92 haul type=0 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.042989 :em_configuration.cpp:843: INFO: BSSID=02:02:11:ec:07:95 haul type=1 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043019 :em_configuration.cpp:843: INFO: BSSID=02:02:12:ec:07:96 haul type=2 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043075 :em_configuration.cpp:1658: INFO: Found AP MLD details in topology response message
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043101 :em_configuration.cpp:1692: INFO: No of AP MLDs: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043130 :em_configuration.cpp:1661: INFO: No of AP MLDs: 1
process_msg:5106 em_msg_type_topo_resp handle success, state: em_state_ctrl_topo_synchronized
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043165 :dm_easy_mesh_ctrl.cpp:1983: INFO: -----Updating network topology <start>-------
find_topology:207: Trying to find topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:9e
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043224 :dm_easy_mesh_ctrl.cpp:1989: INFO: New dev_mac:02:01:00:ec:07:ae num_bss:3 added in topology.
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043280 :dm_easy_mesh.cpp:2213: INFO: dev_mac:02:01:00:ec:07:ae, num_bss:3
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043320 :em_network_topo.cpp:135: INFO: Backhaul sta bss not found for dev_mac:02:01:00:ec:07:ae, return NULL
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043352 :em_network_topo.cpp:264: INFO: Could not find topology in backhaul association tree, must be ethernet
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043402 :em_network_topo.cpp:241: INFO: Adding new topology for dev_mac:02:01:00:ec:07:ae parent dev_mac:02:01:00:ec:07:9e
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043427 :em_network_topo.cpp:249: INFO: No child topologies to add to the new topo: 02:01:00:ec:07:ae
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043457 :dm_easy_mesh_ctrl.cpp:2005: INFO: -----Updating network topology <end>-------
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043530 :em_network_topo.cpp:191: INFO: Network Topology of dev_mac:02:01:00:ec:07:9e num_child_topologies:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043573 :em_network_topo.cpp:192: INFO: ---- Child Topologies[02:01:00:ec:07:9e] <start> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043612 :em_network_topo.cpp:191: INFO: Network Topology of dev_mac:02:01:00:ec:07:ae num_child_topologies:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043642 :em_network_topo.cpp:192: INFO: ---- Child Topologies[02:01:00:ec:07:ae] <start> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043665 :em_network_topo.cpp:196: INFO: ---- Child Topologies[02:01:00:ec:07:ae] <end> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:21.043689 :em_network_topo.cpp:196: INFO: ---- Child Topologies[02:01:00:ec:07:9e] <end> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.037709 :em_configuration.cpp:373: INFO: Topology Query (5) Sent for radio:02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.037802 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.041096 :em_configuration.cpp:373: INFO: Topology Query (4) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.041163 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046007 :em_configuration.cpp:835: INFO: Number of radios: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046090 :em_configuration.cpp:838: INFO: Radio: 02:02:20:ec:07:93
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046118 :em_configuration.cpp:840: INFO: Number of bss: 4
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046147 :em_configuration.cpp:843: INFO: BSSID=02:02:20:ec:07:93 haul type=0 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046203 :em_configuration.cpp:843: INFO: BSSID=02:02:21:ec:07:97 haul type=1 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046232 :em_configuration.cpp:843: INFO: BSSID=02:02:22:ec:07:98 haul type=2 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046260 :em_configuration.cpp:843: INFO: BSSID=00:00:00:00:00:00 haul type=1 vap_mode:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046319 :em_configuration.cpp:1658: INFO: Found AP MLD details in topology response message
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046344 :em_configuration.cpp:1692: INFO: No of AP MLDs: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046373 :em_configuration.cpp:1661: INFO: No of AP MLDs: 1
process_msg:5106 em_msg_type_topo_resp handle success, state: em_state_ctrl_topo_synchronized
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046407 :dm_easy_mesh_ctrl.cpp:1983: INFO: -----Updating network topology <start>-------
find_topology:207: Trying to find topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:9e
find_topology:207: Trying to find topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:ae
find_topology:210: Found topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:ae
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046519 :dm_easy_mesh_ctrl.cpp:1994: INFO: Update dev_mac:02:01:00:ec:07:ae num_bss:7 already in topology.
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046583 :em_network_topo.cpp:292: INFO: Found and Removed topology of dev_mac:02:01:00:ec:07:ae in parent dm:02:01:00:ec:07:9e num_child_topos:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046654 :dm_easy_mesh.cpp:2213: INFO: dev_mac:02:01:00:ec:07:ae, num_bss:7
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046737 :dm_easy_mesh.cpp:2228: INFO: radio_mac:02:02:20:ec:07:93 backhaul bss_mac:00:00:00:00:00:00 radio enabled:1 sta_info enabled:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046778 :em_network_topo.cpp:152: INFO: Find topology associated with bss mac: 00:00:00:00:00:00
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046807 :em_network_topo.cpp:154: INFO: bss mac is zero, return NULL
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046845 :em_network_topo.cpp:264: INFO: Could not find topology in backhaul association tree, must be ethernet
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046899 :em_network_topo.cpp:241: INFO: Adding new topology for dev_mac:02:01:00:ec:07:ae parent dev_mac:02:01:00:ec:07:9e
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046933 :em_network_topo.cpp:249: INFO: No child topologies to add to the new topo: 02:01:00:ec:07:ae
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046963 :dm_easy_mesh_ctrl.cpp:2005: INFO: -----Updating network topology <end>-------
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.046998 :em_network_topo.cpp:191: INFO: Network Topology of dev_mac:02:01:00:ec:07:9e num_child_topologies:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.047024 :em_network_topo.cpp:192: INFO: ---- Child Topologies[02:01:00:ec:07:9e] <start> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.047056 :em_network_topo.cpp:191: INFO: Network Topology of dev_mac:02:01:00:ec:07:ae num_child_topologies:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.047079 :em_network_topo.cpp:192: INFO: ---- Child Topologies[02:01:00:ec:07:ae] <start> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.047108 :em_network_topo.cpp:196: INFO: ---- Child Topologies[02:01:00:ec:07:ae] <end> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:22.047131 :em_network_topo.cpp:196: INFO: ---- Child Topologies[02:01:00:ec:07:9e] <end> -----
orch_execute:151: dm_orch_type_channel_pref(em_cmd_type_em_config) state: em_state_ctrl_topo_synchronized
[onewifi_em_ctrl] 09/16/2025 - 05:38:23.041447 :em_configuration.cpp:373: INFO: Topology Query (5) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:23.041537 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:23.043931 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_query_pending in config state machine.
send_channel_pref_query_msg:966: Channel Pref Query (1) Send Successful
orch_execute:151: dm_orch_type_channel_pref(em_cmd_type_em_config) state: em_state_ctrl_topo_synchronized
[onewifi_em_ctrl] 09/16/2025 - 05:38:24.041803 :em_configuration.cpp:373: INFO: Topology Query (6) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:24.041879 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:24.044308 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:24.044401 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:24.047344 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_query_pending in config state machine.
send_channel_pref_query_msg:966: Channel Pref Query (1) Send Successful
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.042312 :em_configuration.cpp:373: INFO: Topology Query (7) Sent for radio:02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.042487 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_topo_sync_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.044571 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.044686 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.047668 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.047789 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049619 :em_configuration.cpp:835: INFO: Number of radios: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049723 :em_configuration.cpp:838: INFO: Radio: 02:02:30:ec:07:94
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049756 :em_configuration.cpp:840: INFO: Number of bss: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049787 :em_configuration.cpp:843: INFO: BSSID=02:02:30:ec:07:94 haul type=0 vap_mode:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049866 :em_configuration.cpp:1658: INFO: Found AP MLD details in topology response message
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049895 :em_configuration.cpp:1692: INFO: No of AP MLDs: 1
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049928 :em_configuration.cpp:1661: INFO: No of AP MLDs: 1
process_msg:5106 em_msg_type_topo_resp handle success, state: em_state_ctrl_topo_synchronized
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.049971 :dm_easy_mesh_ctrl.cpp:1983: INFO: -----Updating network topology <start>-------
find_topology:207: Trying to find topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:9e
find_topology:207: Trying to find topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:ae
find_topology:210: Found topology: 02:01:00:ec:07:ae in branch: 02:01:00:ec:07:ae
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050060 :dm_easy_mesh_ctrl.cpp:1994: INFO: Update dev_mac:02:01:00:ec:07:ae num_bss:8 already in topology.
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050119 :em_network_topo.cpp:292: INFO: Found and Removed topology of dev_mac:02:01:00:ec:07:ae in parent dm:02:01:00:ec:07:9e num_child_topos:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050170 :dm_easy_mesh.cpp:2213: INFO: dev_mac:02:01:00:ec:07:ae, num_bss:8
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050245 :dm_easy_mesh.cpp:2228: INFO: radio_mac:02:02:20:ec:07:93 backhaul bss_mac:00:00:00:00:00:00 radio enabled:1 sta_info enabled:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050289 :em_network_topo.cpp:152: INFO: Find topology associated with bss mac: 00:00:00:00:00:00
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050316 :em_network_topo.cpp:154: INFO: bss mac is zero, return NULL
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050351 :em_network_topo.cpp:264: INFO: Could not find topology in backhaul association tree, must be ethernet
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050396 :em_network_topo.cpp:241: INFO: Adding new topology for dev_mac:02:01:00:ec:07:ae parent dev_mac:02:01:00:ec:07:9e
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050428 :em_network_topo.cpp:249: INFO: No child topologies to add to the new topo: 02:01:00:ec:07:ae
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050457 :dm_easy_mesh_ctrl.cpp:2005: INFO: -----Updating network topology <end>-------
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050489 :em_network_topo.cpp:191: INFO: Network Topology of dev_mac:02:01:00:ec:07:9e num_child_topologies:1
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050512 :em_network_topo.cpp:192: INFO: ---- Child Topologies[02:01:00:ec:07:9e] <start> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050541 :em_network_topo.cpp:191: INFO: Network Topology of dev_mac:02:01:00:ec:07:ae num_child_topologies:0
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050568 :em_network_topo.cpp:192: INFO: ---- Child Topologies[02:01:00:ec:07:ae] <start> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050590 :em_network_topo.cpp:196: INFO: ---- Child Topologies[02:01:00:ec:07:ae] <end> -----
[onewifi_em_ctrl] 09/16/2025 - 05:38:25.050614 :em_network_topo.cpp:196: INFO: ---- Child Topologies[02:01:00:ec:07:9e] <end> -----
get_dm_orch_type:127: Device: 02:02:10:ec:07:92 already in list
get_dm_orch_type:127: Device: 02:02:20:ec:07:93 already in list
get_dm_orch_type:127: Device: 02:02:30:ec:07:94 already in list
update_tables:1779: Op Class[0] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 81	Class: 81
update_tables:1779: Op Class[1] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 115	Class: 115
update_tables:1779: Op Class[2] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 135	Class: 135
update_tables:1779: Op Class[3] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 81	Class: 81
update_tables:1779: Op Class[4] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 115	Class: 115
update_tables:1779: Op Class[5] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 135	Class: 135
update_tables:1779: Op Class[6] ruid: 02:02:10:ec:07:92	Type: 2	Class: 81	Class: 81
update_tables:1779: Op Class[7] ruid: 02:02:10:ec:07:92	Type: 2	Class: 83	Class: 83
update_tables:1779: Op Class[8] ruid: 02:02:10:ec:07:92	Type: 2	Class: 84	Class: 84
update_tables:1779: Op Class[9] ruid: 02:02:20:ec:07:93	Type: 2	Class: 115	Class: 115
update_tables:1779: Op Class[10] ruid: 02:02:20:ec:07:93	Type: 2	Class: 116	Class: 116
update_tables:1779: Op Class[11] ruid: 02:02:20:ec:07:93	Type: 2	Class: 117	Class: 117
update_tables:1779: Op Class[12] ruid: 02:02:20:ec:07:93	Type: 2	Class: 118	Class: 118
update_tables:1779: Op Class[13] ruid: 02:02:20:ec:07:93	Type: 2	Class: 119	Class: 119
update_tables:1779: Op Class[14] ruid: 02:02:20:ec:07:93	Type: 2	Class: 120	Class: 120
update_tables:1779: Op Class[15] ruid: 02:02:20:ec:07:93	Type: 2	Class: 121	Class: 121
update_tables:1779: Op Class[16] ruid: 02:02:20:ec:07:93	Type: 2	Class: 122	Class: 122
update_tables:1779: Op Class[17] ruid: 02:02:20:ec:07:93	Type: 2	Class: 123	Class: 123
update_tables:1779: Op Class[18] ruid: 02:02:20:ec:07:93	Type: 2	Class: 124	Class: 124
update_tables:1779: Op Class[19] ruid: 02:02:20:ec:07:93	Type: 2	Class: 125	Class: 125
update_tables:1779: Op Class[20] ruid: 02:02:20:ec:07:93	Type: 2	Class: 126	Class: 126
update_tables:1779: Op Class[21] ruid: 02:02:20:ec:07:93	Type: 2	Class: 127	Class: 127
update_tables:1779: Op Class[22] ruid: 02:02:20:ec:07:93	Type: 2	Class: 128	Class: 128
update_tables:1779: Op Class[23] ruid: 02:02:20:ec:07:93	Type: 2	Class: 129	Class: 129
update_tables:1779: Op Class[24] ruid: 02:02:20:ec:07:93	Type: 2	Class: 130	Class: 130
update_tables:1779: Op Class[25] ruid: 02:02:30:ec:07:94	Type: 2	Class: 131	Class: 131
update_tables:1779: Op Class[26] ruid: 02:02:30:ec:07:94	Type: 2	Class: 132	Class: 132
update_tables:1779: Op Class[27] ruid: 02:02:30:ec:07:94	Type: 2	Class: 133	Class: 133
update_tables:1779: Op Class[28] ruid: 02:02:30:ec:07:94	Type: 2	Class: 134	Class: 134
update_tables:1779: Op Class[29] ruid: 02:02:30:ec:07:94	Type: 2	Class: 135	Class: 135
update_tables:1779: Op Class[30] ruid: 02:02:30:ec:07:94	Type: 2	Class: 136	Class: 136
update_tables:1779: Op Class[31] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 81	Class: 81
update_tables:1779: Op Class[32] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 83	Class: 83
update_tables:1779: Op Class[33] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 84	Class: 84
update_tables:1779: Op Class[34] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 115	Class: 115
update_tables:1779: Op Class[35] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 116	Class: 116
update_tables:1779: Op Class[36] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 117	Class: 117
update_tables:1779: Op Class[37] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 118	Class: 118
update_tables:1779: Op Class[38] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 119	Class: 119
update_tables:1779: Op Class[39] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 120	Class: 120
update_tables:1779: Op Class[40] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 121	Class: 121
update_tables:1779: Op Class[41] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 122	Class: 122
update_tables:1779: Op Class[42] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 123	Class: 123
update_tables:1779: Op Class[43] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 124	Class: 124
update_tables:1779: Op Class[44] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 125	Class: 125
update_tables:1779: Op Class[45] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 126	Class: 126
update_tables:1779: Op Class[46] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 127	Class: 127
update_tables:1779: Op Class[47] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 128	Class: 128
update_tables:1779: Op Class[48] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 129	Class: 129
update_tables:1779: Op Class[49] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 130	Class: 130

orch_execute:151: dm_orch_type_channel_pref(em_cmd_type_em_config) state: em_state_ctrl_topo_synchronized
orch_execute:151: dm_orch_type_channel_sel(em_cmd_type_em_config) state: em_state_ctrl_channel_queried
orch_execute:151: dm_orch_type_channel_sel(em_cmd_type_em_config) state: em_state_ctrl_channel_queried
[onewifi_em_ctrl] 09/16/2025 - 05:38:28.050924 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_query_pending in config state machine.
send_channel_pref_query_msg:966: Channel Pref Query (1) Send Successful
[onewifi_em_ctrl] 09/16/2025 - 05:38:28.052977 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_select_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:28.053863 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_select_pending in config state machine.
handle_channel_sel_rsp:1689 Received channel selection response
handle_channel_sel_rsp:1689 Received channel selection response
[onewifi_em_ctrl] 09/16/2025 - 05:38:29.051253 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:29.051350 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_pref_report_pending in channel state machine.
get_dm_orch_type:127: Device: 02:02:10:ec:07:92 already in list
get_dm_orch_type:127: Device: 02:02:20:ec:07:93 already in list
get_dm_orch_type:127: Device: 02:02:30:ec:07:94 already in list
update_tables:1779: Op Class[0] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 81	Class: 81
update_tables:1779: Op Class[1] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 115	Class: 115
update_tables:1779: Op Class[2] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 135	Class: 135
update_tables:1779: Op Class[3] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 81	Class: 81
update_tables:1779: Op Class[4] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 115	Class: 115
update_tables:1779: Op Class[5] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 135	Class: 135
update_tables:1779: Op Class[6] ruid: 02:02:10:ec:07:92	Type: 2	Class: 81	Class: 81
update_tables:1779: Op Class[7] ruid: 02:02:10:ec:07:92	Type: 2	Class: 83	Class: 83
update_tables:1779: Op Class[8] ruid: 02:02:10:ec:07:92	Type: 2	Class: 84	Class: 84
update_tables:1779: Op Class[9] ruid: 02:02:20:ec:07:93	Type: 2	Class: 115	Class: 115
update_tables:1779: Op Class[10] ruid: 02:02:20:ec:07:93	Type: 2	Class: 116	Class: 116
update_tables:1779: Op Class[11] ruid: 02:02:20:ec:07:93	Type: 2	Class: 117	Class: 117
update_tables:1779: Op Class[12] ruid: 02:02:20:ec:07:93	Type: 2	Class: 118	Class: 118
update_tables:1779: Op Class[13] ruid: 02:02:20:ec:07:93	Type: 2	Class: 119	Class: 119
update_tables:1779: Op Class[14] ruid: 02:02:20:ec:07:93	Type: 2	Class: 120	Class: 120
update_tables:1779: Op Class[15] ruid: 02:02:20:ec:07:93	Type: 2	Class: 121	Class: 121
update_tables:1779: Op Class[16] ruid: 02:02:20:ec:07:93	Type: 2	Class: 122	Class: 122
update_tables:1779: Op Class[17] ruid: 02:02:20:ec:07:93	Type: 2	Class: 123	Class: 123
update_tables:1779: Op Class[18] ruid: 02:02:20:ec:07:93	Type: 2	Class: 124	Class: 124
update_tables:1779: Op Class[19] ruid: 02:02:20:ec:07:93	Type: 2	Class: 125	Class: 125
update_tables:1779: Op Class[20] ruid: 02:02:20:ec:07:93	Type: 2	Class: 126	Class: 126
update_tables:1779: Op Class[21] ruid: 02:02:20:ec:07:93	Type: 2	Class: 127	Class: 127
update_tables:1779: Op Class[22] ruid: 02:02:20:ec:07:93	Type: 2	Class: 128	Class: 128
update_tables:1779: Op Class[23] ruid: 02:02:20:ec:07:93	Type: 2	Class: 129	Class: 129
update_tables:1779: Op Class[24] ruid: 02:02:20:ec:07:93	Type: 2	Class: 130	Class: 130
update_tables:1779: Op Class[25] ruid: 02:02:30:ec:07:94	Type: 2	Class: 131	Class: 131
update_tables:1779: Op Class[26] ruid: 02:02:30:ec:07:94	Type: 2	Class: 132	Class: 132
update_tables:1779: Op Class[27] ruid: 02:02:30:ec:07:94	Type: 2	Class: 133	Class: 133
update_tables:1779: Op Class[28] ruid: 02:02:30:ec:07:94	Type: 2	Class: 134	Class: 134
update_tables:1779: Op Class[29] ruid: 02:02:30:ec:07:94	Type: 2	Class: 135	Class: 135
update_tables:1779: Op Class[30] ruid: 02:02:30:ec:07:94	Type: 2	Class: 136	Class: 136
update_tables:1779: Op Class[31] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 81	Class: 81
update_tables:1779: Op Class[32] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 83	Class: 83
update_tables:1779: Op Class[33] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 84	Class: 84
update_tables:1779: Op Class[34] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 115	Class: 115
update_tables:1779: Op Class[35] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 116	Class: 116
update_tables:1779: Op Class[36] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 117	Class: 117
update_tables:1779: Op Class[37] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 118	Class: 118
update_tables:1779: Op Class[38] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 119	Class: 119
update_tables:1779: Op Class[39] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 120	Class: 120
update_tables:1779: Op Class[40] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 121	Class: 121
update_tables:1779: Op Class[41] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 122	Class: 122
update_tables:1779: Op Class[42] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 123	Class: 123
update_tables:1779: Op Class[43] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 124	Class: 124
update_tables:1779: Op Class[44] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 125	Class: 125
update_tables:1779: Op Class[45] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 126	Class: 126
update_tables:1779: Op Class[46] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 127	Class: 127
update_tables:1779: Op Class[47] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 128	Class: 128
update_tables:1779: Op Class[48] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 129	Class: 129
update_tables:1779: Op Class[49] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 130	Class: 130
update_tables:1779: Op Class[50] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 131	Class: 131
update_tables:1779: Op Class[51] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 132	Class: 132
update_tables:1779: Op Class[52] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 133	Class: 133
update_tables:1779: Op Class[53] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 134	Class: 134
update_tables:1779: Op Class[54] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 135	Class: 135
update_tables:1779: Op Class[55] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 136	Class: 136

handle_operating_channel_rprt:1717 Operating channel report recv
get_dm_orch_type:127: Device: 02:02:10:ec:07:92 already in list
get_dm_orch_type:127: Device: 02:02:20:ec:07:93 already in list
get_dm_orch_type:127: Device: 02:02:30:ec:07:94 already in list
update_tables:1779: Op Class[0] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 81	Class: 81
update_tables:1779: Op Class[1] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 115	Class: 115
update_tables:1779: Op Class[2] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 135	Class: 135
update_tables:1779: Op Class[3] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 81	Class: 81
update_tables:1779: Op Class[4] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 115	Class: 115
update_tables:1779: Op Class[5] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 135	Class: 135
update_tables:1779: Op Class[6] ruid: 02:02:10:ec:07:92	Type: 2	Class: 81	Class: 81
update_tables:1779: Op Class[7] ruid: 02:02:10:ec:07:92	Type: 2	Class: 83	Class: 83
update_tables:1779: Op Class[8] ruid: 02:02:10:ec:07:92	Type: 2	Class: 84	Class: 84
update_tables:1779: Op Class[9] ruid: 02:02:20:ec:07:93	Type: 2	Class: 115	Class: 115
update_tables:1779: Op Class[10] ruid: 02:02:20:ec:07:93	Type: 2	Class: 116	Class: 116
update_tables:1779: Op Class[11] ruid: 02:02:20:ec:07:93	Type: 2	Class: 117	Class: 117
update_tables:1779: Op Class[12] ruid: 02:02:20:ec:07:93	Type: 2	Class: 118	Class: 118
update_tables:1779: Op Class[13] ruid: 02:02:20:ec:07:93	Type: 2	Class: 119	Class: 119
update_tables:1779: Op Class[14] ruid: 02:02:20:ec:07:93	Type: 2	Class: 120	Class: 120
update_tables:1779: Op Class[15] ruid: 02:02:20:ec:07:93	Type: 2	Class: 121	Class: 121
update_tables:1779: Op Class[16] ruid: 02:02:20:ec:07:93	Type: 2	Class: 122	Class: 122
update_tables:1779: Op Class[17] ruid: 02:02:20:ec:07:93	Type: 2	Class: 123	Class: 123
update_tables:1779: Op Class[18] ruid: 02:02:20:ec:07:93	Type: 2	Class: 124	Class: 124
update_tables:1779: Op Class[19] ruid: 02:02:20:ec:07:93	Type: 2	Class: 125	Class: 125
update_tables:1779: Op Class[20] ruid: 02:02:20:ec:07:93	Type: 2	Class: 126	Class: 126
update_tables:1779: Op Class[21] ruid: 02:02:20:ec:07:93	Type: 2	Class: 127	Class: 127
update_tables:1779: Op Class[22] ruid: 02:02:20:ec:07:93	Type: 2	Class: 128	Class: 128
update_tables:1779: Op Class[23] ruid: 02:02:20:ec:07:93	Type: 2	Class: 129	Class: 129
update_tables:1779: Op Class[24] ruid: 02:02:20:ec:07:93	Type: 2	Class: 130	Class: 130
update_tables:1779: Op Class[25] ruid: 02:02:30:ec:07:94	Type: 2	Class: 131	Class: 131
update_tables:1779: Op Class[26] ruid: 02:02:30:ec:07:94	Type: 2	Class: 132	Class: 132
update_tables:1779: Op Class[27] ruid: 02:02:30:ec:07:94	Type: 2	Class: 133	Class: 133
update_tables:1779: Op Class[28] ruid: 02:02:30:ec:07:94	Type: 2	Class: 134	Class: 134
update_tables:1779: Op Class[29] ruid: 02:02:30:ec:07:94	Type: 2	Class: 135	Class: 135
update_tables:1779: Op Class[30] ruid: 02:02:30:ec:07:94	Type: 2	Class: 136	Class: 136
update_tables:1779: Op Class[31] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 81	Class: 81
update_tables:1779: Op Class[32] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 83	Class: 83
update_tables:1779: Op Class[33] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 84	Class: 84
update_tables:1779: Op Class[34] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 115	Class: 115
update_tables:1779: Op Class[35] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 116	Class: 116
update_tables:1779: Op Class[36] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 117	Class: 117
update_tables:1779: Op Class[37] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 118	Class: 118
update_tables:1779: Op Class[38] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 119	Class: 119
update_tables:1779: Op Class[39] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 120	Class: 120
update_tables:1779: Op Class[40] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 121	Class: 121
update_tables:1779: Op Class[41] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 122	Class: 122
update_tables:1779: Op Class[42] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 123	Class: 123
update_tables:1779: Op Class[43] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 124	Class: 124
update_tables:1779: Op Class[44] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 125	Class: 125
update_tables:1779: Op Class[45] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 126	Class: 126
update_tables:1779: Op Class[46] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 127	Class: 127
update_tables:1779: Op Class[47] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 128	Class: 128
update_tables:1779: Op Class[48] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 129	Class: 129
update_tables:1779: Op Class[49] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 130	Class: 130
update_tables:1779: Op Class[50] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 131	Class: 131
update_tables:1779: Op Class[51] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 132	Class: 132
update_tables:1779: Op Class[52] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 133	Class: 133
update_tables:1779: Op Class[53] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 134	Class: 134
update_tables:1779: Op Class[54] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 135	Class: 135
update_tables:1779: Op Class[55] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 136	Class: 136
update_tables:1779: Op Class[56] ruid: 02:02:10:ec:07:92	Type: 1	Class: 12	Class: 12

orch_execute:151: dm_orch_type_channel_sel(em_cmd_type_em_config) state: em_state_ctrl_channel_queried
orch_execute:151: dm_orch_type_channel_cnf(em_cmd_type_em_config) state: em_state_ctrl_configured
orch_execute:151: dm_orch_type_channel_cnf(em_cmd_type_em_config) state: em_state_ctrl_channel_selected
[onewifi_em_ctrl] 09/16/2025 - 05:38:32.057274 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_select_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:32.062922 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:32.063041 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in channel state machine.
handle_operating_channel_rprt:1717 Operating channel report recv
handle_channel_sel_rsp:1689 Received channel selection response
get_dm_orch_type:127: Device: 02:02:10:ec:07:92 already in list
get_dm_orch_type:127: Device: 02:02:20:ec:07:93 already in list
get_dm_orch_type:127: Device: 02:02:30:ec:07:94 already in list
update_tables:1779: Op Class[0] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 81	Class: 81
update_tables:1779: Op Class[1] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 115	Class: 115
update_tables:1779: Op Class[2] ruid: 02:01:00:ec:07:ae	Type: 7	Class: 135	Class: 135
update_tables:1779: Op Class[3] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 81	Class: 81
update_tables:1779: Op Class[4] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 115	Class: 115
update_tables:1779: Op Class[5] ruid: 02:01:00:ec:07:ae	Type: 8	Class: 135	Class: 135
update_tables:1779: Op Class[6] ruid: 02:02:10:ec:07:92	Type: 2	Class: 81	Class: 81
update_tables:1779: Op Class[7] ruid: 02:02:10:ec:07:92	Type: 2	Class: 83	Class: 83
update_tables:1779: Op Class[8] ruid: 02:02:10:ec:07:92	Type: 2	Class: 84	Class: 84
update_tables:1779: Op Class[9] ruid: 02:02:20:ec:07:93	Type: 2	Class: 115	Class: 115
update_tables:1779: Op Class[10] ruid: 02:02:20:ec:07:93	Type: 2	Class: 116	Class: 116
update_tables:1779: Op Class[11] ruid: 02:02:20:ec:07:93	Type: 2	Class: 117	Class: 117
update_tables:1779: Op Class[12] ruid: 02:02:20:ec:07:93	Type: 2	Class: 118	Class: 118
update_tables:1779: Op Class[13] ruid: 02:02:20:ec:07:93	Type: 2	Class: 119	Class: 119
update_tables:1779: Op Class[14] ruid: 02:02:20:ec:07:93	Type: 2	Class: 120	Class: 120
update_tables:1779: Op Class[15] ruid: 02:02:20:ec:07:93	Type: 2	Class: 121	Class: 121
update_tables:1779: Op Class[16] ruid: 02:02:20:ec:07:93	Type: 2	Class: 122	Class: 122
update_tables:1779: Op Class[17] ruid: 02:02:20:ec:07:93	Type: 2	Class: 123	Class: 123
update_tables:1779: Op Class[18] ruid: 02:02:20:ec:07:93	Type: 2	Class: 124	Class: 124
update_tables:1779: Op Class[19] ruid: 02:02:20:ec:07:93	Type: 2	Class: 125	Class: 125
update_tables:1779: Op Class[20] ruid: 02:02:20:ec:07:93	Type: 2	Class: 126	Class: 126
update_tables:1779: Op Class[21] ruid: 02:02:20:ec:07:93	Type: 2	Class: 127	Class: 127
update_tables:1779: Op Class[22] ruid: 02:02:20:ec:07:93	Type: 2	Class: 128	Class: 128
update_tables:1779: Op Class[23] ruid: 02:02:20:ec:07:93	Type: 2	Class: 129	Class: 129
update_tables:1779: Op Class[24] ruid: 02:02:20:ec:07:93	Type: 2	Class: 130	Class: 130
update_tables:1779: Op Class[25] ruid: 02:02:30:ec:07:94	Type: 2	Class: 131	Class: 131
update_tables:1779: Op Class[26] ruid: 02:02:30:ec:07:94	Type: 2	Class: 132	Class: 132
update_tables:1779: Op Class[27] ruid: 02:02:30:ec:07:94	Type: 2	Class: 133	Class: 133
update_tables:1779: Op Class[28] ruid: 02:02:30:ec:07:94	Type: 2	Class: 134	Class: 134
update_tables:1779: Op Class[29] ruid: 02:02:30:ec:07:94	Type: 2	Class: 135	Class: 135
update_tables:1779: Op Class[30] ruid: 02:02:30:ec:07:94	Type: 2	Class: 136	Class: 136
update_tables:1779: Op Class[31] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 81	Class: 81
update_tables:1779: Op Class[32] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 83	Class: 83
update_tables:1779: Op Class[33] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 84	Class: 84
update_tables:1779: Op Class[34] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 115	Class: 115
update_tables:1779: Op Class[35] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 116	Class: 116
update_tables:1779: Op Class[36] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 117	Class: 117
update_tables:1779: Op Class[37] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 118	Class: 118
update_tables:1779: Op Class[38] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 119	Class: 119
update_tables:1779: Op Class[39] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 120	Class: 120
update_tables:1779: Op Class[40] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 121	Class: 121
update_tables:1779: Op Class[41] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 122	Class: 122
update_tables:1779: Op Class[42] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 123	Class: 123
update_tables:1779: Op Class[43] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 124	Class: 124
update_tables:1779: Op Class[44] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 125	Class: 125
update_tables:1779: Op Class[45] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 126	Class: 126
update_tables:1779: Op Class[46] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 127	Class: 127
update_tables:1779: Op Class[47] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 128	Class: 128
update_tables:1779: Op Class[48] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 129	Class: 129
update_tables:1779: Op Class[49] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 130	Class: 130
update_tables:1779: Op Class[50] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 131	Class: 131
update_tables:1779: Op Class[51] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 132	Class: 132
update_tables:1779: Op Class[52] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 133	Class: 133
update_tables:1779: Op Class[53] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 134	Class: 134
update_tables:1779: Op Class[54] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 135	Class: 135
update_tables:1779: Op Class[55] ruid: 02:01:00:ec:07:ae	Type: 6	Class: 136	Class: 136
update_tables:1779: Op Class[56] ruid: 02:02:10:ec:07:92	Type: 1	Class: 12	Class: 12
update_tables:1779: Op Class[57] ruid: 02:02:20:ec:07:93	Type: 1	Class: 1	Class: 1

orch_execute:151: dm_orch_type_channel_cnf(em_cmd_type_em_config) state: em_state_ctrl_channel_selected
orch_execute:151: dm_orch_type_policy_cfg(em_cmd_type_em_config) state: em_state_ctrl_configured
orch_execute:151: dm_orch_type_policy_cfg(em_cmd_type_em_config) state: em_state_ctrl_configured
[onewifi_em_ctrl] 09/16/2025 - 05:38:35.060756 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_set_policy_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:35.060875 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_set_policy_pending in channel state machine.
send_policy_cfg_request_msg:430: Policy Cfg Request Msg Send Success
[onewifi_em_ctrl] 09/16/2025 - 05:38:35.063541 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_set_policy_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:35.063686 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_set_policy_pending in channel state machine.
send_policy_cfg_request_msg:430: Policy Cfg Request Msg Send Success
[onewifi_em_ctrl] 09/16/2025 - 05:38:35.065798 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:35.065897 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:36.062021 :em_configuration.cpp:1460: INFO: Topology Notification received, length: 50
[onewifi_em_ctrl] 09/16/2025 - 05:38:36.066046 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:36.066175 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:37.066331 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:37.066447 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:38.066603 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:38.066708 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in channel state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:39.066846 :em_configuration.cpp:5300: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in config state machine.
[onewifi_em_ctrl] 09/16/2025 - 05:38:39.066977 :em_channel.cpp:2018: INFO: unhandled state:em_state_ctrl_channel_cnf_pending in channel state machine.
em_agent_logs
root@Filogic-GW:~# cat /tmp/em_agent.log
Registration completed with MAC Address: 2 1 0 ec 7 ae
mgr_input_listen:290 Thread stack size = 8388608 bytes
mgr_nodes_listen:436 Thread stack size = 8388608 bytes
input_listener:1087 he_bus open success
input_listener:1105 recv data:
{
	"Version":	"1.0",
	"SubDocName":	"dml",
	"WifiConfig":	{
		"GASConfig":	{
			"AdvertisementId":	0,
			"PauseForServerResp":	true,
			"RespTimeout":	5000,
			"ComebackDelay":	1000,
			"RespBufferTime":	1000,
			"QueryRespLengthLimit":	127
		},
		"NotifyWifiChanges":	false,
		"PreferPrivate":	false,
		"PreferPrivateConfigure":	false,
		"FactoryReset":	false,
		"TxOverflowSelfheal":	false,
		"InstWifiClientEnabled":	false,
		"InstWifiClientReportingPeriod":	0,
		"InstWifiClientMac":	"00:00:00:00:00:00",
		"InstWifiClientDefReportingPeriod":	0,
		"WifiActiveMsmtEnabled":	false,
		"WifiActiveMsmtPktsize":	0,
		"WifiActiveMsmtNumSamples":	0,
		"WifiActiveMsmtSampleDuration":	0,
		"VlanCfgVersion":	0,
		"WpsPin":	"",
		"BandsteeringEnable":	false,
		"GoodRssiThreshold":	0,
		"AssocCountThreshold":	0,
		"AssocGateTime":	0,
		"WhixLoginterval":	0,
		"whix_chutility_loginterval":	0,
		"rss_memory_restart_threshold_low":	0,
		"rss_memory_restart_threshold_high":	0,
		"AssocMonitorDuration":	0,
		"RapidReconnectEnable":	false,
		"VapStatsFeature":	false,
		"MfpConfigFeature":	false,
		"ForceDisableRadioFeature":	false,
		"ForceDisableRadioStatus":	false,
		"FixedWmmParams":	0,
		"WifiRegionCode":	"",
		"DiagnosticEnable":	false,
		"ValidateSsid":	false,
		"DeviceNetworkMode":	0,
		"NormalizedRssiList":	"",
		"SNRList":	"",
		"CliStatList":	"",
		"TxRxRateList":	"",
		"MgtFrameRateLimitEnable":	false,
		"MgtFrameRateLimit":	0,
		"MgtFrameRateLimitWindowSize":	0,
		"MgtFrameRateLimitCooldownTime":	0,
		"rss_check_interval":	0,
		"rss_threshold":	0,
		"rss_maxlimit":	0,
		"heapwalk_duration":	0,
		"heapwalk_interval":	0,
		"MemwrapToolEnable":	false
	},
	"WifiRadioConfig":	[{
			"WifiRadioSetup":	{
				"RadioIndex":	0,
				"VapMap":	[{
						"VapName":	"private_ssid_2g",
						"VapIndex":	0
					}, {
						"VapName":	"mesh_backhaul_2g",
						"VapIndex":	12
					}, {
						"VapName":	"iot_ssid_2g",
						"VapIndex":	2
					}]
			},
			"RadioName":	"radio1",
			"Enabled":	true,
			"FreqBand":	1,
			"AutoChannelEnabled":	true,
			"Channel":	6,
			"NumSecondaryChannels":	0,
			"SecondaryChannelsList":	" ",
			"ChannelWidth":	1,
			"HwMode":	268,
			"CsaBeaconCount":	100,
			"Country":	"US",
			"RegDomain":	0,
			"OperatingEnvironment":	"I",
			"DFSEnable":	false,
			"DfsEnabledBootup":	false,
			"ChannelAvailability":	"1:1,2:1,3:1,4:1,5:1,6:1,7:1,8:1,9:1,10:1,11:1,12:1,13:1,14:1",
			"radarInfo":	"last_channel:0,num_detected:0,time:0",
			"DcsEnabled":	false,
			"DtimPeriod":	1,
			"OperatingClass":	12,
			"BasicDataTransmitRates":	656,
			"OperationalDataTransmitRates":	8112,
			"FragmentationThreshold":	2346,
			"GuardInterval":	16,
			"TransmitPower":	100,
			"BeaconInterval":	100,
			"RtsThreshold":	2347,
			"FactoryResetSsid":	false,
			"RadioStatsMeasuringRate":	0,
			"RadioStatsMeasuringInterval":	0,
			"CtsProtection":	false,
			"ObssCoex":	true,
			"StbcEnable":	true,
			"GreenFieldEnable":	false,
			"UserControl":	0,
			"AdminControl":	0,
			"ChanUtilThreshold":	90,
			"ChanUtilSelfHealEnable":	false,
			"EcoPowerDown":	false,
			"Tscan":	0,
			"Nscan":	0,
			"Tidle":	0,
			"DfsTimer":	30,
			"RadarDetected":	" ",
			"Amsdu_Tid":	"0,0,0,0,0,0,0,0",
			"NumberOfOpClass":	3,
			"OperatingClasses":	[{
					"NumberOfNonOperChan":	2,
					"Class":	81,
					"MaxTxPower":	-30,
					"NonOperable":	[12, 13]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	83,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	2,
					"Class":	84,
					"MaxTxPower":	-30,
					"NonOperable":	[12, 13]
				}],
			"CurrentOperatingClasses":	[{
					"Class":	12,
					"Channel":	6
				}]
		}, {
			"WifiRadioSetup":	{
				"RadioIndex":	1,
				"VapMap":	[{
						"VapName":	"private_ssid_5g",
						"VapIndex":	1
					}, {
						"VapName":	"mesh_backhaul_5g",
						"VapIndex":	13
					}, {
						"VapName":	"iot_ssid_5g",
						"VapIndex":	3
					}, {
						"VapName":	"mesh_sta_5g",
						"VapIndex":	15
					}]
			},
			"RadioName":	"radio2",
			"Enabled":	true,
			"FreqBand":	2,
			"AutoChannelEnabled":	true,
			"Channel":	36,
			"NumSecondaryChannels":	0,
			"SecondaryChannelsList":	" ",
			"ChannelWidth":	4,
			"HwMode":	425,
			"CsaBeaconCount":	100,
			"Country":	"US",
			"RegDomain":	0,
			"OperatingEnvironment":	"I",
			"DFSEnable":	false,
			"DfsEnabledBootup":	false,
			"ChannelAvailability":	"36:1,40:1,44:1,48:1,52:2,56:2,60:2,64:2,100:2,104:2,108:2,112:2,116:2,120:2,124:2,128:2,132:2,136:2,140:2,144:2,149:1,153:1,157:1,161:1,165:1,169:1,173:1,177:1",
			"radarInfo":	"last_channel:0,num_detected:0,time:0",
			"DcsEnabled":	false,
			"DtimPeriod":	1,
			"OperatingClass":	1,
			"BasicDataTransmitRates":	656,
			"OperationalDataTransmitRates":	8112,
			"FragmentationThreshold":	2346,
			"GuardInterval":	16,
			"TransmitPower":	100,
			"BeaconInterval":	100,
			"RtsThreshold":	2347,
			"FactoryResetSsid":	false,
			"RadioStatsMeasuringRate":	0,
			"RadioStatsMeasuringInterval":	0,
			"CtsProtection":	false,
			"ObssCoex":	true,
			"StbcEnable":	true,
			"GreenFieldEnable":	false,
			"UserControl":	0,
			"AdminControl":	0,
			"ChanUtilThreshold":	90,
			"ChanUtilSelfHealEnable":	false,
			"EcoPowerDown":	false,
			"Tscan":	63,
			"Nscan":	8,
			"Tidle":	5,
			"DfsTimer":	30,
			"RadarDetected":	" ",
			"Amsdu_Tid":	"0,0,0,0,0,0,0,0",
			"NumberOfOpClass":	16,
			"OperatingClasses":	[{
					"NumberOfNonOperChan":	0,
					"Class":	115,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	116,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	117,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	118,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	119,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	120,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	121,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	122,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	123,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	124,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	2,
					"Class":	125,
					"MaxTxPower":	-30,
					"NonOperable":	[169, 173]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	126,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	1,
					"Class":	127,
					"MaxTxPower":	-30,
					"NonOperable":	[169]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	128,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	129,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	130,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}],
			"CurrentOperatingClasses":	[{
					"Class":	1,
					"Channel":	36
				}]
		}, {
			"WifiRadioSetup":	{
				"RadioIndex":	2,
				"VapMap":	[{
						"VapName":	"private_ssid_6g",
						"VapIndex":	16
					}]
			},
			"RadioName":	"radio3",
			"Enabled":	true,
			"FreqBand":	16,
			"AutoChannelEnabled":	true,
			"Channel":	5,
			"NumSecondaryChannels":	0,
			"SecondaryChannelsList":	" ",
			"ChannelWidth":	8,
			"HwMode":	384,
			"CsaBeaconCount":	100,
			"Country":	"US",
			"RegDomain":	0,
			"OperatingEnvironment":	"I",
			"DFSEnable":	false,
			"DfsEnabledBootup":	false,
			"ChannelAvailability":	"1:1,5:1,9:1,13:1,17:1,21:1,25:1,29:1,33:1,37:1,41:1,45:1,49:1,53:1,57:1,61:1,65:1,69:1,73:1,77:1,81:1,85:1,89:1,93:1,97:1,101:1,105:1,109:1,113:1,117:1,121:1,125:1,129:1,133:1,137:1,141:1,145:1,149:1,153:1,157:1,161:1,165:1,169:1,173:1,177:1,181:1,185:1,189:1,193:1,197:1,201:1,205:1,209:1,213:1,217:1,221:1,225:1,229:1,233:1",
			"radarInfo":	"last_channel:0,num_detected:0,time:0",
			"DcsEnabled":	false,
			"DtimPeriod":	1,
			"OperatingClass":	134,
			"BasicDataTransmitRates":	656,
			"OperationalDataTransmitRates":	8112,
			"FragmentationThreshold":	2346,
			"GuardInterval":	16,
			"TransmitPower":	100,
			"BeaconInterval":	100,
			"RtsThreshold":	2347,
			"FactoryResetSsid":	false,
			"RadioStatsMeasuringRate":	0,
			"RadioStatsMeasuringInterval":	0,
			"CtsProtection":	false,
			"ObssCoex":	true,
			"StbcEnable":	true,
			"GreenFieldEnable":	false,
			"UserControl":	0,
			"AdminControl":	0,
			"ChanUtilThreshold":	90,
			"ChanUtilSelfHealEnable":	false,
			"EcoPowerDown":	false,
			"Tscan":	0,
			"Nscan":	0,
			"Tidle":	0,
			"DfsTimer":	30,
			"RadarDetected":	" ",
			"Amsdu_Tid":	"0,0,0,0,0,0,0,0",
			"NumberOfOpClass":	6,
			"OperatingClasses":	[{
					"NumberOfNonOperChan":	0,
					"Class":	131,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	132,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	133,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	1,
					"Class":	134,
					"MaxTxPower":	23,
					"NonOperable":	[169]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	135,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	136,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}],
			"CurrentOperatingClasses":	[{
					"Class":	134,
					"Channel":	5
				}]
		}],
	"DeviceInfo":	{
		"Manufacturer":	"BananapiBPI-R4",
		"Model":	"BananapiBPI-R4",
		"SerialNo":	"62734efb37aa4e27a6eb3d4ecddb382b",
		"Software_version":	"rdkb-generic-broadband-image_rdk-next_20250916053725",
		"CMMAC":	"02:01:00:ec:07:8e",
		"AL1905-MAC":	"02:01:00:ec:07:9e"
	},
	"WiFiCap":	{
		"WiFiRadioCap":	[{
				"RadioIndex":	0,
				"PossibleChannels":	[1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14],
				"PossibleChannelWidths":	[1, 2],
				"RadioPresence":	1
			}, {
				"RadioIndex":	0,
				"PossibleChannels":	[36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165, 169, 173, 177],
				"PossibleChannelWidths":	[1, 2, 4, 8],
				"RadioPresence":	1
			}, {
				"RadioIndex":	0,
				"PossibleChannels":	[1, 5, 9, 13, 17, 21, 25, 29, 33, 37, 41, 45, 49, 53, 57, 61, 65, 69, 73, 77, 81, 85, 89, 93, 97, 101, 105, 109, 113, 117, 121, 125, 129, 133, 137, 141, 145, 149, 153, 157, 161, 165, 169, 173, 177, 181, 185, 189, 193, 197, 201, 205, 209, 213, 217, 221, 225, 229, 233],
				"PossibleChannelWidths":	[1, 2, 4, 8, 32],
				"RadioPresence":	1
			}],
		"WiFiVapCap":	[{
				"VapName":	"private_ssid_2g",
				"PhyIndex":	0,
				"RadioIndex":	0,
				"InterfaceName":	"wifi0",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	0
			}, {
				"VapName":	"mesh_backhaul_2g",
				"PhyIndex":	0,
				"RadioIndex":	0,
				"InterfaceName":	"wifi0.1",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	12
			}, {
				"VapName":	"iot_ssid_2g",
				"PhyIndex":	0,
				"RadioIndex":	0,
				"InterfaceName":	"wifi0.2",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	2
			}, {
				"VapName":	"private_ssid_5g",
				"PhyIndex":	0,
				"RadioIndex":	1,
				"InterfaceName":	"wifi1",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	1
			}, {
				"VapName":	"mesh_backhaul_5g",
				"PhyIndex":	0,
				"RadioIndex":	1,
				"InterfaceName":	"wifi1.1",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	13
			}, {
				"VapName":	"iot_ssid_5g",
				"PhyIndex":	0,
				"RadioIndex":	1,
				"InterfaceName":	"wifi1.2",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	3
			}, {
				"VapName":	"mesh_sta_5g",
				"PhyIndex":	0,
				"RadioIndex":	1,
				"InterfaceName":	"wifi1.3",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	15
			}, {
				"VapName":	"private_ssid_6g",
				"PhyIndex":	0,
				"RadioIndex":	2,
				"InterfaceName":	"wifi2",
				"BridgeName":	"brlan0",
				"VLANID":	0,
				"Index":	16
			}],
		"WiFiRadioInterfaceCap":	[{
				"PhyIndex":	0,
				"RadioIndex":	0,
				"InterfaceName":	"wifi0"
			}, {
				"PhyIndex":	0,
				"RadioIndex":	1,
				"InterfaceName":	"wifi1"
			}, {
				"PhyIndex":	0,
				"RadioIndex":	2,
				"InterfaceName":	"wifi2"
			}]
	},
	"WifiVapConfig":	[{
			"VapName":	"private_ssid_2g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	0,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:10:ec:07:92",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	true,
			"NeighborReportActivated":	true,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	true,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	true,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	true,
			"WpsConfigMethodsEnabled":	128,
			"WpsConfigPin":	"1234567",
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	true,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA3-Personal-Transition",
				"MFPConfig":	"Optional",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"mesh_backhaul_2g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	0,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:11:ec:07:95",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	true,
			"MacFilterMode":	1,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"iot_ssid_2g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	0,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:12:ec:07:96",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	false,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"private_ssid_5g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	1,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:20:ec:07:93",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	true,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	1,
			"MLD_Addr":	"02:02:30:ec:07:95",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	true,
			"NeighborReportActivated":	true,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	true,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	true,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	true,
			"WpsConfigMethodsEnabled":	128,
			"WpsConfigPin":	"1234567",
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	true,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA3-Personal-Transition",
				"MFPConfig":	"Optional",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"mesh_backhaul_5g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	1,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:21:ec:07:97",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	true,
			"MacFilterMode":	1,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"iot_ssid_5g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	1,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:22:ec:07:98",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	false,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"mesh_sta_5g",
			"BridgeName":	"brlan0",
			"VapMode":	1,
			"RadioIndex":	1,
			"Exists":	true,
			"SSID":	"mesh_backhaul",
			"BSSID":	"00:00:00:00:00:00",
			"MAC":	"02:02:23:ec:07:99",
			"Enabled":	false,
			"ConnectStatus":	false,
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-backhaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"ScanParameters":	{
				"Period":	10,
				"Channel":	0
			}
		}, {
			"VapName":	"private_ssid_6g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	2,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"BPI-RDKB-MLO-AP",
			"BSSID":	"02:02:30:ec:07:94",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	true,
			"NeighborReportActivated":	true,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	true,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	true,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	true,
			"WpsConfigMethodsEnabled":	128,
			"WpsConfigPin":	"1234567",
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	true,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA3-Personal",
				"MFPConfig":	"Required",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"rdk@1234",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}],
	"WifiMacFilter":	[{
			"VapName":	"private_ssid_2g",
			"MACFilterList":	[]
		}, {
			"VapName":	"mesh_backhaul_2g",
			"MACFilterList":	[]
		}, {
			"VapName":	"iot_ssid_2g",
			"MACFilterList":	[]
		}, {
			"VapName":	"private_ssid_5g",
			"MACFilterList":	[]
		}, {
			"VapName":	"mesh_backhaul_5g",
			"MACFilterList":	[]
		}, {
			"VapName":	"iot_ssid_5g",
			"MACFilterList":	[]
		}, {
			"VapName":	"mesh_sta_5g",
			"MACFilterList":	[]
		}, {
			"VapName":	"private_ssid_6g",
			"MACFilterList":	[]
		}]
}
[onewifi_em_agent] 09/16/2025 - 05:38:14.923949 :em_agent.cpp:1141: INFO: Failed to subscribe to 'Device.WiFi.EC.BSSInfo', dynamic DPP channel list for Reconfiguration Announcement is not available
get_listener_socket:203: bind error on socket: 6, err:98
execute:63: listener socket get failed, service:0
[onewifi_em_agent] 09/16/2025 - 05:38:14.927378 :dm_easy_mesh.cpp:2820: INFO: m_num_ap_mld 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.927424 :dm_easy_mesh.cpp:2838: INFO: Created new MLD at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.927437 :dm_easy_mesh.cpp:2874: INFO: Added new affiliated AP at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.927447 :dm_easy_mesh.cpp:2886: INFO: Updated MLD with 1 affiliated APs
translate_onewifi_dml_data:225 Dev-Init decode success
analyze_dev_init:80 al_mac = 02:01:00:ec:07:ae
print_config:1943:Network:02:01:00:ec:07:9e
print_config:1944:Controller MAC:02:01:00:ec:07:8e	Controller AL MAC:02:01:00:ec:07:ae	Agent AL MAC:02:01:00:ec:07:ae
print_config:1946:Manufacturer:BananapiBPI-R4	Manufacturere Model:BananapiBPI-R4	SoftwareVersion:rdkb-generic-broadband-image_rdktestEnv0250916053725
print_config:1961:No of BSS=8 No of Radios=3
print_config:1964:Radio Mac : 02:02:10:ec:07:92 BSSID : 02:02:10:ec:07:92
print_config:1964:Radio Mac : 02:02:10:ec:07:92 BSSID : 02:02:11:ec:07:95
print_config:1964:Radio Mac : 02:02:10:ec:07:92 BSSID : 02:02:12:ec:07:96
print_config:1964:Radio Mac : 02:02:20:ec:07:93 BSSID : 02:02:20:ec:07:93
print_config:1964:Radio Mac : 02:02:20:ec:07:93 BSSID : 02:02:21:ec:07:97
print_config:1964:Radio Mac : 02:02:20:ec:07:93 BSSID : 02:02:22:ec:07:98
print_config:1964:Radio Mac : 02:02:20:ec:07:93 BSSID : 00:00:00:00:00:00
print_config:1964:Radio Mac : 02:02:30:ec:07:94 BSSID : 02:02:30:ec:07:94
print_config:1972:Radio Mac: 02:02:10:ec:07:92
print_config:1973:Radio Band: 0
print_config:1974:TransmitPowerLimit: 0
print_config:1972:Radio Mac: 02:02:20:ec:07:93
print_config:1973:Radio Band: 1
print_config:1974:TransmitPowerLimit: 0
print_config:1972:Radio Mac: 02:02:30:ec:07:94
print_config:1973:Radio Band: 2
print_config:1974:TransmitPowerLimit: 0
pre_process_orch_op:222: calling create node
create_node:203 key value used:02:01:00:ec:07:ae_al
[onewifi_em_agent] 09/16/2025 - 05:38:14.939260 :em.cpp:1873: INFO: Co-located enrollee detected, regenerating net-access-key and connector
[onewifi_em_agent] 09/16/2025 - 05:38:14.944838 :em.cpp:1894: INFO: Generated new persistent security context for colocated agent
EC Manager created with MAC: 02:01:00:ec:07:ae
create_node:224: created entry for key:02:01:00:ec:07:ae_al
pre_process_orch_op:233: AL node created
em_func:558 Thread stack size = 8388608 bytes
commit_config:136 New Radio 02:02:10:ec:07:92 configuration created no of radios=1
commit_config:162 New op class=81 commiting it
commit_config:162 New op class=83 commiting it
commit_config:162 New op class=84 commiting it
commit_config:162 New op class=12 commiting it
commit_config:170 Commit radio=02:02:10:ec:07:92
commit_config:188 New BSS 02:02:10:ec:07:92 configuration updated  no of bss=1 vapname=private_ssid_2g
commit_config:188 New BSS 02:02:11:ec:07:95 configuration updated  no of bss=2 vapname=mesh_backhaul_2g
commit_config:188 New BSS 02:02:12:ec:07:96 configuration updated  no of bss=3 vapname=iot_ssid_2g
[onewifi_em_agent] 09/16/2025 - 05:38:14.955104 :dm_easy_mesh.cpp:193: INFO: Number of AP MLDs to commit : 1
[onewifi_em_agent] 09/16/2025 - 05:38:14.955162 :dm_easy_mesh.cpp:2820: INFO: m_num_ap_mld 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.955178 :dm_easy_mesh.cpp:2838: INFO: Created new MLD at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.955188 :dm_easy_mesh.cpp:2874: INFO: Added new affiliated AP at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.955198 :dm_easy_mesh.cpp:2886: INFO: Updated MLD with 1 affiliated APs
pre_process_orch_op:250: calling create_node band=0
create_node:203 key value used:02:02:10:ec:07:92
create_node:224: created entry for key:02:02:10:ec:07:92
em_func:558 Thread stack size = 8388608 bytes
commit_config:136 New Radio 02:02:20:ec:07:93 configuration created no of radios=2
commit_config:162 New op class=115 commiting it
commit_config:162 New op class=116 commiting it
commit_config:162 New op class=117 commiting it
commit_config:162 New op class=118 commiting it
commit_config:162 New op class=119 commiting it
commit_config:162 New op class=120 commiting it
commit_config:162 New op class=121 commiting it
commit_config:162 New op class=122 commiting it
commit_config:162 New op class=123 commiting it
commit_config:162 New op class=124 commiting it
commit_config:162 New op class=125 commiting it
commit_config:162 New op class=126 commiting it
commit_config:162 New op class=127 commiting it
commit_config:162 New op class=128 commiting it
commit_config:162 New op class=129 commiting it
commit_config:162 New op class=130 commiting it
commit_config:162 New op class=1 commiting it
commit_config:170 Commit radio=02:02:20:ec:07:93
commit_config:188 New BSS 02:02:20:ec:07:93 configuration updated  no of bss=4 vapname=private_ssid_5g
commit_config:188 New BSS 02:02:21:ec:07:97 configuration updated  no of bss=5 vapname=mesh_backhaul_5g
commit_config:188 New BSS 02:02:22:ec:07:98 configuration updated  no of bss=6 vapname=iot_ssid_5g
commit_config:188 New BSS 00:00:00:00:00:00 configuration updated  no of bss=7 vapname=mesh_sta_5g
[onewifi_em_agent] 09/16/2025 - 05:38:14.966312 :dm_easy_mesh.cpp:193: INFO: Number of AP MLDs to commit : 1
[onewifi_em_agent] 09/16/2025 - 05:38:14.966362 :dm_easy_mesh.cpp:2820: INFO: m_num_ap_mld 1
[onewifi_em_agent] 09/16/2025 - 05:38:14.966376 :dm_easy_mesh.cpp:2824: INFO: Found existing MLD at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.966387 :dm_easy_mesh.cpp:2861: INFO: Found existing affiliated AP at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.966396 :dm_easy_mesh.cpp:2886: INFO: Updated MLD with 1 affiliated APs
pre_process_orch_op:250: calling create_node band=1
create_node:203 key value used:02:02:20:ec:07:93
create_node:224: created entry for key:02:02:20:ec:07:93
em_func:558 Thread stack size = 8388608 bytes
commit_config:136 New Radio 02:02:30:ec:07:94 configuration created no of radios=3
commit_config:162 New op class=131 commiting it
commit_config:162 New op class=132 commiting it
commit_config:162 New op class=133 commiting it
commit_config:162 New op class=134 commiting it
commit_config:162 New op class=135 commiting it
commit_config:162 New op class=136 commiting it
commit_config:162 New op class=134 commiting it
commit_config:170 Commit radio=02:02:30:ec:07:94
commit_config:188 New BSS 02:02:30:ec:07:94 configuration updated  no of bss=8 vapname=private_ssid_6g
[onewifi_em_agent] 09/16/2025 - 05:38:14.976942 :dm_easy_mesh.cpp:193: INFO: Number of AP MLDs to commit : 1
[onewifi_em_agent] 09/16/2025 - 05:38:14.976988 :dm_easy_mesh.cpp:2820: INFO: m_num_ap_mld 1
[onewifi_em_agent] 09/16/2025 - 05:38:14.977000 :dm_easy_mesh.cpp:2824: INFO: Found existing MLD at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.977010 :dm_easy_mesh.cpp:2861: INFO: Found existing affiliated AP at index 0
[onewifi_em_agent] 09/16/2025 - 05:38:14.977019 :dm_easy_mesh.cpp:2886: INFO: Updated MLD with 1 affiliated APs
pre_process_orch_op:250: calling create_node band=2
create_node:203 key value used:02:02:30:ec:07:94
create_node:224: created entry for key:02:02:30:ec:07:94
em_func:558 Thread stack size = 8388608 bytes
[onewifi_em_agent] 09/16/2025 - 05:38:14.989262 :em_agent.cpp:183: INFO: Subscribed to receive management action frames for VAP 12
send_result:119: write error on socket, err:88
handle_state_config_none:5201: autoconfig_search send successful
handle_state_config_none:5201: autoconfig_search send successful
[onewifi_em_agent] 09/16/2025 - 05:38:15.978526 :em_configuration.cpp:4907: INFO: Received autoconfig resp from 02:01:00:ec:07:9e
Received resp and validated...creating M1 msg
Op Class 0: 81, max_tx_eirp: -30, channels.num: 2
 cap->op_classes[0].op_class: 81, cap->op_classes[0].max_tx_eirp 226,	cap->op_classes[0].channels.num 2
Op Class 1: 83, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[1].op_class: 12, cap->op_classes[1].max_tx_eirp 13,	cap->op_classes[1].channels.num 83
Op Class 2: 84, max_tx_eirp: -30, channels.num: 2
 cap->op_classes[2].op_class: 226, cap->op_classes[2].max_tx_eirp 0,	cap->op_classes[2].channels.num 84
[onewifi_em_agent] 09/16/2025 - 05:38:15.978622 :em.cpp:951: INFO: Created AP Radio Basic Cap TLV for Radio:02:02:10:ec:07:92, num_bss:3, op_class_num:3, len:21
[onewifi_em_agent] 09/16/2025 - 05:38:15.978638 :em_configuration.cpp:2353: INFO: WPS Auth Flags: 0x0000
[onewifi_em_agent] 09/16/2025 - 05:38:15.978678 :em_configuration.cpp:4952: INFO: autoconfig wsc m1 send success, len:559
[onewifi_em_agent] 09/16/2025 - 05:38:15.985389 :em_configuration.cpp:4907: INFO: Received autoconfig resp from 02:01:00:ec:07:9e
Received resp and validated...creating M1 msg
Op Class 4: 115, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[4].op_class: 0, cap->op_classes[4].max_tx_eirp 0,	cap->op_classes[4].channels.num 0
Op Class 5: 116, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[5].op_class: 0, cap->op_classes[5].max_tx_eirp 0,	cap->op_classes[5].channels.num 0
Op Class 6: 117, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[6].op_class: 0, cap->op_classes[6].max_tx_eirp 0,	cap->op_classes[6].channels.num 0
Op Class 7: 118, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[7].op_class: 0, cap->op_classes[7].max_tx_eirp 0,	cap->op_classes[7].channels.num 0
Op Class 8: 119, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[8].op_class: 0, cap->op_classes[8].max_tx_eirp 0,	cap->op_classes[8].channels.num 0
Op Class 9: 120, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[9].op_class: 0, cap->op_classes[9].max_tx_eirp 0,	cap->op_classes[9].channels.num 0
Op Class 10: 121, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[10].op_class: 0, cap->op_classes[10].max_tx_eirp 0,	cap->op_classes[10].channels.num 0
Op Class 11: 122, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[11].op_class: 0, cap->op_classes[11].max_tx_eirp 0,	cap->op_classes[11].channels.num 0
Op Class 12: 123, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[12].op_class: 0, cap->op_classes[12].max_tx_eirp 0,	cap->op_classes[12].channels.num 0
Op Class 13: 124, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[13].op_class: 0, cap->op_classes[13].max_tx_eirp 0,	cap->op_classes[13].channels.num 0
Op Class 14: 125, max_tx_eirp: -30, channels.num: 2
 cap->op_classes[14].op_class: 0, cap->op_classes[14].max_tx_eirp 0,	cap->op_classes[14].channels.num 0
Op Class 15: 126, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[15].op_class: 0, cap->op_classes[15].max_tx_eirp 0,	cap->op_classes[15].channels.num 1
Op Class 16: 127, max_tx_eirp: -30, channels.num: 1
 cap->op_classes[16].op_class: 128, cap->op_classes[16].max_tx_eirp 194,	cap->op_classes[16].channels.num 0
Op Class 17: 128, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[17].op_class: 0, cap->op_classes[17].max_tx_eirp 19,	cap->op_classes[17].channels.num 2
Op Class 18: 129, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[18].op_class: 1, cap->op_classes[18].max_tx_eirp 0,	cap->op_classes[18].channels.num 236
Op Class 19: 130, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[19].op_class: 7, cap->op_classes[19].max_tx_eirp 174,	cap->op_classes[19].channels.num 137
[onewifi_em_agent] 09/16/2025 - 05:38:15.985496 :em.cpp:951: INFO: Created AP Radio Basic Cap TLV for Radio:02:02:20:ec:07:93, num_bss:4, op_class_num:16, len:59
[onewifi_em_agent] 09/16/2025 - 05:38:15.985518 :em_configuration.cpp:2353: INFO: WPS Auth Flags: 0x0000
[onewifi_em_agent] 09/16/2025 - 05:38:15.985560 :em_configuration.cpp:4952: INFO: autoconfig wsc m1 send success, len:597
handle_state_config_none:5201: autoconfig_search send successful
find_em_for_msg_type:1491: Found existing radio:02:02:10:ec:07:92
process_msg:5080: received wsc_m2 len:1036
handle_wsc_m2:3507: Parsing m2 message, len: 911
[onewifi_em_agent] 09/16/2025 - 05:38:16.026840 :em_configuration.cpp:3722: INFO: Found AP MLD details in message
[onewifi_em_agent] 09/16/2025 - 05:38:16.026902 :em_configuration.cpp:1687: INFO: Zero AP MLD data
find_em_for_msg_type:1491: Found existing radio:02:02:20:ec:07:93
process_msg:5080: received wsc_m2 len:1036
handle_wsc_m2:3507: Parsing m2 message, len: 911
[onewifi_em_agent] 09/16/2025 - 05:38:16.046030 :em_configuration.cpp:3722: INFO: Found AP MLD details in message
[onewifi_em_agent] 09/16/2025 - 05:38:16.046096 :em_configuration.cpp:1687: INFO: Zero AP MLD data
handle_autoconfig_wsc_m2:3736: Authenticator verification succeeded
handle_encrypted_settings:3792: noofbss configuration recv=4
handle_encrypted_settings:3803: ssid attrib: private_ssid
handle_encrypted_settings:3813: network key attrib: test-fronthaul
handle_encrypted_settings:3816: mac address attrib: 02:02:10:ec:07:92
handle_encrypted_settings:3819: key wrap auth attrib
handle_encrypted_settings:3803: ssid attrib: mesh_backhaul
handle_encrypted_settings:3813: network key attrib: test-backhaul
handle_encrypted_settings:3816: mac address attrib: 02:02:10:ec:07:92
handle_encrypted_settings:3819: key wrap auth attrib
handle_encrypted_settings:3803: ssid attrib: iot_ssid
handle_encrypted_settings:3813: network key attrib: test-backhaul
handle_encrypted_settings:3816: mac address attrib: 02:02:10:ec:07:92
handle_encrypted_settings:3819: key wrap auth attrib
handle_encrypted_settings:3803: ssid attrib: lnf_radius
handle_encrypted_settings:3813: network key attrib: test-backhaul
handle_encrypted_settings:3816: mac address attrib: 02:02:10:ec:07:92
handle_encrypted_settings:3819: key wrap auth attrib
analyze_m2ctrl_configuration:250 New configuration SSID=private_ssid  passphrase=test-fronthaul haultype=0 radiomac=02:02:10:ec:07:92
analyze_m2ctrl_configuration:250 New configuration SSID=mesh_backhaul  passphrase=test-backhaul haultype=1 radiomac=02:02:10:ec:07:92
analyze_m2ctrl_configuration:250 New configuration SSID=iot_ssid  passphrase=test-backhaul haultype=2 radiomac=02:02:10:ec:07:92
analyze_m2ctrl_configuration:250 New configuration SSID=lnf_radius  passphrase=test-backhaul haultype=3 radiomac=02:02:10:ec:07:92
[onewifi_em_agent] 09/16/2025 - 05:38:16.051382 :ec_enrollee.cpp:41: INFO: Enrollee is upgrading, skipping cleanup of persistent security context
refresh_onewifi_subdoc:976 Private subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"Vap_2.4G",
	"Primary MacAddress":	"02:02:10:ec:07:92",
	"WifiVapConfig":	[{
			"VapName":	"private_ssid_2g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	0,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"private_ssid",
			"BSSID":	"02:02:10:ec:07:92",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	true,
			"NeighborReportActivated":	true,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	true,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	true,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	true,
			"WpsConfigMethodsEnabled":	128,
			"WpsConfigPin":	"1234567",
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	true,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Optional",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-fronthaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"mesh_backhaul_2g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	0,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"mesh_backhaul",
			"BSSID":	"02:02:11:ec:07:95",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	true,
			"MacFilterMode":	1,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-backhaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"iot_ssid_2g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	0,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"iot_ssid",
			"BSSID":	"02:02:12:ec:07:96",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	false,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-backhaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}]
}
[onewifi_em_agent] 09/16/2025 - 05:38:16.052222 :ec_1905_encrypt_layer.cpp:557: INFO: Initialized 1905 layer encryption with security parameters
[onewifi_em_agent] 09/16/2025 - 05:38:16.052268 :ec_manager.cpp:165: INFO: Upgraded enrollee agent to proxy agent
refresh_onewifi_subdoc:993 Private subdoc send successfull
handle_autoconfig_wsc_m2:3736: Authenticator verification succeeded
handle_encrypted_settings:3792: noofbss configuration recv=4
handle_encrypted_settings:3803: ssid attrib: private_ssid
handle_encrypted_settings:3813: network key attrib: test-fronthaul
handle_encrypted_settings:3816: mac address attrib: 02:02:20:ec:07:93
handle_encrypted_settings:3819: key wrap auth attrib
handle_encrypted_settings:3803: ssid attrib: mesh_backhaul
handle_encrypted_settings:3813: network key attrib: test-backhaul
handle_encrypted_settings:3816: mac address attrib: 02:02:20:ec:07:93
handle_encrypted_settings:3819: key wrap auth attrib
handle_encrypted_settings:3803: ssid attrib: iot_ssid
handle_encrypted_settings:3813: network key attrib: test-backhaul
handle_encrypted_settings:3816: mac address attrib: 02:02:20:ec:07:93
handle_encrypted_settings:3819: key wrap auth attrib
handle_encrypted_settings:3803: ssid attrib: lnf_radius
handle_encrypted_settings:3813: network key attrib: test-backhaul
handle_encrypted_settings:3816: mac address attrib: 02:02:20:ec:07:93
handle_encrypted_settings:3819: key wrap auth attrib
analyze_m2ctrl_configuration:250 New configuration SSID=private_ssid  passphrase=test-fronthaul haultype=0 radiomac=02:02:20:ec:07:93
analyze_m2ctrl_configuration:250 New configuration SSID=mesh_backhaul  passphrase=test-backhaul haultype=1 radiomac=02:02:20:ec:07:93
analyze_m2ctrl_configuration:250 New configuration SSID=iot_ssid  passphrase=test-backhaul haultype=2 radiomac=02:02:20:ec:07:93
analyze_m2ctrl_configuration:250 New configuration SSID=lnf_radius  passphrase=test-backhaul haultype=3 radiomac=02:02:20:ec:07:93
[onewifi_em_agent] 09/16/2025 - 05:38:16.065899 :ec_manager.cpp:141: INFO: Can't upgrade an already upgraded agent
refresh_onewifi_subdoc:976 Private subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"Vap_5G",
	"Primary MacAddress":	"02:02:20:ec:07:93",
	"WifiVapConfig":	[{
			"VapName":	"private_ssid_5g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	1,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"private_ssid",
			"BSSID":	"02:02:20:ec:07:93",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	true,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	1,
			"MLD_Addr":	"02:02:30:ec:07:95",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	true,
			"NeighborReportActivated":	true,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	true,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	true,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	true,
			"WpsConfigMethodsEnabled":	128,
			"WpsConfigPin":	"1234567",
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	true,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Optional",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-fronthaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"mesh_backhaul_5g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	1,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"mesh_backhaul",
			"BSSID":	"02:02:21:ec:07:97",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	true,
			"MacFilterMode":	1,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-backhaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"iot_ssid_5g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	1,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"iot_ssid",
			"BSSID":	"02:02:22:ec:07:98",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	false,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	false,
			"NeighborReportActivated":	false,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	false,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	false,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	false,
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	false,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-backhaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}, {
			"VapName":	"mesh_sta_5g",
			"BridgeName":	"brlan0",
			"VapMode":	1,
			"RadioIndex":	1,
			"Exists":	true,
			"SSID":	"mesh_backhaul",
			"BSSID":	"00:00:00:00:00:00",
			"MAC":	"02:02:23:ec:07:99",
			"Enabled":	true,
			"ConnectStatus":	false,
			"Security":	{
				"Mode":	"WPA2-Personal",
				"MFPConfig":	"Disabled",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-backhaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"ScanParameters":	{
				"Period":	10,
				"Channel":	0
			}
		}]
}
refresh_onewifi_subdoc:993 Private subdoc send successfull
handle_state_config_none:5201: autoconfig_search send successful
[onewifi_em_agent] 09/16/2025 - 05:38:16.995510 :em_configuration.cpp:4907: INFO: Received autoconfig resp from 02:01:00:ec:07:9e
Received resp and validated...creating M1 msg
Op Class 21: 131, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[21].op_class: 0, cap->op_classes[21].max_tx_eirp 7,	cap->op_classes[21].channels.num 0
Op Class 22: 132, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[22].op_class: 7, cap->op_classes[22].max_tx_eirp 0,	cap->op_classes[22].channels.num 128
Op Class 23: 133, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[23].op_class: 1, cap->op_classes[23].max_tx_eirp 0,	cap->op_classes[23].channels.num 6
Op Class 24: 134, max_tx_eirp: 23, channels.num: 1
 cap->op_classes[24].op_class: 2, cap->op_classes[24].max_tx_eirp 1,	cap->op_classes[24].channels.num 0
Op Class 25: 135, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[25].op_class: 236, cap->op_classes[25].max_tx_eirp 7,	cap->op_classes[25].channels.num 174
Op Class 26: 136, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[26].op_class: 13, cap->op_classes[26].max_tx_eirp 0,	cap->op_classes[26].channels.num 1
[onewifi_em_agent] 09/16/2025 - 05:38:16.995630 :em.cpp:951: INFO: Created AP Radio Basic Cap TLV for Radio:02:02:30:ec:07:94, num_bss:1, op_class_num:6, len:27
[onewifi_em_agent] 09/16/2025 - 05:38:16.995646 :em_configuration.cpp:2353: INFO: WPS Auth Flags: 0x0000
[onewifi_em_agent] 09/16/2025 - 05:38:16.995683 :em_configuration.cpp:4952: INFO: autoconfig wsc m1 send success, len:565
[onewifi_em_agent] 09/16/2025 - 05:38:17.034677 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:10:ec:07:92 is in incorrect state state=5
find_em_for_msg_type:1491: Found existing radio:02:02:30:ec:07:94
process_msg:5080: received wsc_m2 len:764
handle_wsc_m2:3507: Parsing m2 message, len: 639
[onewifi_em_agent] 09/16/2025 - 05:38:17.044336 :em_configuration.cpp:3722: INFO: Found AP MLD details in message
[onewifi_em_agent] 09/16/2025 - 05:38:17.044403 :em_configuration.cpp:1687: INFO: Zero AP MLD data
handle_autoconfig_wsc_m2:3736: Authenticator verification succeeded
handle_encrypted_settings:3792: noofbss configuration recv=1
handle_encrypted_settings:3803: ssid attrib: private_ssid
handle_encrypted_settings:3813: network key attrib: test-fronthaul
handle_encrypted_settings:3816: mac address attrib: 02:02:30:ec:07:94
handle_encrypted_settings:3819: key wrap auth attrib
analyze_m2ctrl_configuration:250 New configuration SSID=private_ssid  passphrase=test-fronthaul haultype=0 radiomac=02:02:30:ec:07:94
[onewifi_em_agent] 09/16/2025 - 05:38:17.065847 :ec_manager.cpp:141: INFO: Can't upgrade an already upgraded agent
refresh_onewifi_subdoc:976 Private subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"Vap_6G",
	"Primary MacAddress":	"02:02:30:ec:07:94",
	"WifiVapConfig":	[{
			"VapName":	"private_ssid_6g",
			"BridgeName":	"brlan0",
			"RepurposedBridgeName":	"",
			"RepurposedVapName":	"",
			"RadioIndex":	2,
			"VapMode":	0,
			"Exists":	true,
			"SSID":	"private_ssid",
			"BSSID":	"02:02:30:ec:07:94",
			"Enabled":	true,
			"SSIDAdvertisementEnabled":	true,
			"MLD_Enable":	false,
			"MLD_Apply":	true,
			"MLD_ID":	0,
			"MLD_Link_ID":	0,
			"MLD_Addr":	"00:00:00:00:00:00",
			"SpeedTier":	0,
			"MDUEnabled":	false,
			"IsolationEnable":	false,
			"ManagementFramePowerControl":	0,
			"InteropNumSta":	0,
			"BssMaxNumSta":	75,
			"BSSTransitionActivated":	true,
			"NeighborReportActivated":	true,
			"NetworkGreyList":	false,
			"RapidReconnCountEnable":	true,
			"RapidReconnThreshold":	180,
			"VapStatsEnable":	true,
			"MacFilterEnable":	false,
			"MacFilterMode":	0,
			"WmmEnabled":	true,
			"UapsdEnabled":	true,
			"BeaconRate":	16,
			"WmmNoAck":	0,
			"WepKeyLength":	128,
			"BssHotspot":	false,
			"WpsPushButton":	0,
			"WpsEnable":	true,
			"WpsConfigMethodsEnabled":	128,
			"WpsConfigPin":	"1234567",
			"BeaconRateCtl":	"6Mbps",
			"Connected_building_enabled":	false,
			"HostapMgtFrameCtrl":	false,
			"InteropCtrl":	false,
			"MboEnabled":	true,
			"ExtraVendorIEs":	"",
			"Security":	{
				"Mode":	"WPA3-Personal",
				"MFPConfig":	"Required",
				"EncryptionMethod":	"AES",
				"Wpa3_transition_disable":	false,
				"Passphrase":	"test-fronthaul",
				"KeyId":	"",
				"RekeyInterval":	0
			},
			"Interworking":	{
				"InterworkingEnable":	false,
				"AccessNetworkType":	0,
				"Internet":	false,
				"ASRA":	false,
				"ESR":	false,
				"UESA":	false,
				"HESSOptionPresent":	true,
				"HESSID":	"11:22:33:44:55:66",
				"Venue":	{
					"VenueOptionPresent":	true,
					"VenueType":	0,
					"VenueGroup":	0
				}
			}
		}]
}
refresh_onewifi_subdoc:993 Private subdoc send successfull
[onewifi_em_agent] 09/16/2025 - 05:38:18.035102 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:10:ec:07:92 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:18.038611 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:20:ec:07:93 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:19.036570 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:10:ec:07:92 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:19.039082 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:20:ec:07:93 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:19.043838 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:30:ec:07:94 is in incorrect state state=5
onewifi_cb:1326 Found SubDocName: private
analyze_onewifi_vap_cb:285 Private subdoc decode success
commit_config:170 Commit radio=02:02:10:ec:07:92
commit_config:178 BSS 02:02:10:ec:07:92 configuration updated
commit_config:178 BSS 02:02:11:ec:07:95 configuration updated
commit_config:178 BSS 02:02:12:ec:07:96 configuration updated
[onewifi_em_agent] 09/16/2025 - 05:38:19.677354 :dm_easy_mesh.cpp:193: INFO: Number of AP MLDs to commit : 0
analyze_onewifi_vap_cb:323 02:02:10:ec:07:92 in owconfig
em candidates created for em_cmd_type_onewifi_cb
submitted command for orchestration
[onewifi_em_agent] 09/16/2025 - 05:38:20.035992 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:10:ec:07:92 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:20.039455 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:20:ec:07:93 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:20.042758 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:30:ec:07:94 is in incorrect state state=5
onewifi_cb:1326 Found SubDocName: private
analyze_onewifi_vap_cb:285 Private subdoc decode success
commit_config:170 Commit radio=02:02:20:ec:07:93
commit_config:178 BSS 02:02:20:ec:07:93 configuration updated
commit_config:178 BSS 02:02:21:ec:07:97 configuration updated
commit_config:178 BSS 02:02:22:ec:07:98 configuration updated
commit_config:178 BSS 00:00:00:00:00:00 configuration updated
[onewifi_em_agent] 09/16/2025 - 05:38:20.677171 :dm_easy_mesh.cpp:193: INFO: Number of AP MLDs to commit : 0
analyze_onewifi_vap_cb:323 02:02:20:ec:07:93 in owconfig
em candidates created for em_cmd_type_onewifi_cb
submitted command for orchestration
find_em_for_msg_type:1506: Received topo query, found existing radio:02:02:10:ec:07:92
send_topology_response_msg:934: Testing topo, number of radios: 3, bss: 8
first tlv_len in em_configuration_t::create_operational_bss_tlv = 1
print_ap_operational_bss_tlv:1332 Number of radios: 1
print_ap_operational_bss_tlv:1335: Radio: 02:02:10:ec:07:92
print_ap_operational_bss_tlv:1338 Number of bss: 3
print_ap_operational_bss_tlv:1341: BSS:02:02:10:ec:07:92 SSID:private_ssid, SSID Length: 13
print_ap_operational_bss_tlv:1341: BSS:02:02:11:ec:07:95 SSID:mesh_backhaul, SSID Length: 14
print_ap_operational_bss_tlv:1341: BSS:02:02:12:ec:07:96 SSID:iot_ssid, SSID Length: 9
first tlv_len in em_configuration_t::create_custom_operational_bss_tlv = 0
[onewifi_em_agent] 09/16/2025 - 05:38:21.036352 :em_configuration.cpp:806: INFO: Number of radios: 1
[onewifi_em_agent] 09/16/2025 - 05:38:21.036420 :em_configuration.cpp:809: INFO: Radio: 02:02:10:ec:07:92
[onewifi_em_agent] 09/16/2025 - 05:38:21.036432 :em_configuration.cpp:811: INFO: Number of bss: 3
[onewifi_em_agent] 09/16/2025 - 05:38:21.036443 :em_configuration.cpp:814: INFO: BSSID=02:02:10:ec:07:92 haul type=0 vap_mode:0
[onewifi_em_agent] 09/16/2025 - 05:38:21.036454 :em_configuration.cpp:814: INFO: BSSID=02:02:11:ec:07:95 haul type=1 vap_mode:0
[onewifi_em_agent] 09/16/2025 - 05:38:21.036463 :em_configuration.cpp:814: INFO: BSSID=02:02:12:ec:07:96 haul type=2 vap_mode:0
send_topology_response_msg:1053: Testing topo, frame length: 652
setting state to em_state_agent_topo_synchronized
[onewifi_em_agent] 09/16/2025 - 05:38:21.041163 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:20:ec:07:93 is in incorrect state state=5
[onewifi_em_agent] 09/16/2025 - 05:38:21.044654 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:30:ec:07:94 is in incorrect state state=5
find_em_for_msg_type:1506: Received topo query, found existing radio:02:02:20:ec:07:93
send_topology_response_msg:934: Testing topo, number of radios: 3, bss: 8
first tlv_len in em_configuration_t::create_operational_bss_tlv = 1
print_ap_operational_bss_tlv:1332 Number of radios: 1
print_ap_operational_bss_tlv:1335: Radio: 02:02:20:ec:07:93
print_ap_operational_bss_tlv:1338 Number of bss: 4
print_ap_operational_bss_tlv:1341: BSS:02:02:20:ec:07:93 SSID:private_ssid, SSID Length: 13
print_ap_operational_bss_tlv:1341: BSS:02:02:21:ec:07:97 SSID:mesh_backhaul, SSID Length: 14
print_ap_operational_bss_tlv:1341: BSS:02:02:22:ec:07:98 SSID:iot_ssid, SSID Length: 9
print_ap_operational_bss_tlv:1341: BSS:00:00:00:00:00:00 SSID:mesh_backhaul, SSID Length: 14
first tlv_len in em_configuration_t::create_custom_operational_bss_tlv = 0
[onewifi_em_agent] 09/16/2025 - 05:38:22.040690 :em_configuration.cpp:806: INFO: Number of radios: 1
[onewifi_em_agent] 09/16/2025 - 05:38:22.040739 :em_configuration.cpp:809: INFO: Radio: 02:02:20:ec:07:93
[onewifi_em_agent] 09/16/2025 - 05:38:22.040750 :em_configuration.cpp:811: INFO: Number of bss: 4
[onewifi_em_agent] 09/16/2025 - 05:38:22.040761 :em_configuration.cpp:814: INFO: BSSID=02:02:20:ec:07:93 haul type=0 vap_mode:0
[onewifi_em_agent] 09/16/2025 - 05:38:22.040772 :em_configuration.cpp:814: INFO: BSSID=02:02:21:ec:07:97 haul type=1 vap_mode:0
[onewifi_em_agent] 09/16/2025 - 05:38:22.040782 :em_configuration.cpp:814: INFO: BSSID=02:02:22:ec:07:98 haul type=2 vap_mode:0
[onewifi_em_agent] 09/16/2025 - 05:38:22.040792 :em_configuration.cpp:814: INFO: BSSID=00:00:00:00:00:00 haul type=1 vap_mode:1
send_topology_response_msg:1053: Testing topo, frame length: 683
setting state to em_state_agent_topo_synchronized
[onewifi_em_agent] 09/16/2025 - 05:38:22.043734 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:30:ec:07:94 is in incorrect state state=5
onewifi_cb:1326 Found SubDocName: private
analyze_onewifi_vap_cb:285 Private subdoc decode success
commit_config:170 Commit radio=02:02:30:ec:07:94
commit_config:178 BSS 02:02:30:ec:07:94 configuration updated
[onewifi_em_agent] 09/16/2025 - 05:38:22.676771 :dm_easy_mesh.cpp:193: INFO: Number of AP MLDs to commit : 0
analyze_onewifi_vap_cb:323 02:02:30:ec:07:94 in owconfig
em candidates created for em_cmd_type_onewifi_cb
submitted command for orchestration
[onewifi_em_agent] 09/16/2025 - 05:38:23.044245 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:30:ec:07:94 is in incorrect state state=5
find_em_for_msg_type:1526: Received channel preference query recv, found existing radio:02:02:10:ec:07:92
build_candidates:439 em_cmd_type_channel_pref_query build candidate MAC=02:02:10:ec:07:92
handle_channel_pref_query:208 send success
[onewifi_em_agent] 09/16/2025 - 05:38:24.044253 :em_agent.cpp:1509: INFO: em_msg_type_topo_query :em mac=02:02:30:ec:07:94 is in incorrect state state=5
find_em_for_msg_type:1526: Received channel preference query recv, found existing radio:02:02:20:ec:07:93
build_candidates:439 em_cmd_type_channel_pref_query build candidate MAC=02:02:20:ec:07:93
handle_channel_pref_query:208 send success
find_em_for_msg_type:1506: Received topo query, found existing radio:02:02:30:ec:07:94
send_topology_response_msg:934: Testing topo, number of radios: 3, bss: 8
first tlv_len in em_configuration_t::create_operational_bss_tlv = 1
print_ap_operational_bss_tlv:1332 Number of radios: 1
print_ap_operational_bss_tlv:1335: Radio: 02:02:30:ec:07:94
print_ap_operational_bss_tlv:1338 Number of bss: 1
print_ap_operational_bss_tlv:1341: BSS:02:02:30:ec:07:94 SSID:private_ssid, SSID Length: 13
first tlv_len in em_configuration_t::create_custom_operational_bss_tlv = 0
[onewifi_em_agent] 09/16/2025 - 05:38:25.045207 :em_configuration.cpp:806: INFO: Number of radios: 1
[onewifi_em_agent] 09/16/2025 - 05:38:25.045253 :em_configuration.cpp:809: INFO: Radio: 02:02:30:ec:07:94
[onewifi_em_agent] 09/16/2025 - 05:38:25.045265 :em_configuration.cpp:811: INFO: Number of bss: 1
[onewifi_em_agent] 09/16/2025 - 05:38:25.045276 :em_configuration.cpp:814: INFO: BSSID=02:02:30:ec:07:94 haul type=0 vap_mode:0
send_topology_response_msg:1053: Testing topo, frame length: 592
setting state to em_state_agent_topo_synchronized
send_channel_pref_report_msg:1251: Channel Preference Report send success
process_state:1968 channel_pref_report_msg send
send_channel_pref_report_msg:1251: Channel Preference Report send success
process_state:1968 channel_pref_report_msg send
find_em_for_msg_type:1526: Received channel preference query recv, found existing radio:02:02:30:ec:07:94
build_candidates:439 em_cmd_type_channel_pref_query build candidate MAC=02:02:30:ec:07:94
handle_channel_pref_query:208 send success
find_em_for_msg_type:1549: Received em_msg_type_channel_sel_req, found existing radio:02:02:10:ec:07:92
handle_channel_sel_req:1682 Received channel selection request
analyze_channel_sel_req:414 No of opclass=1 tx=0
refresh_onewifi_subdoc:976 Radio subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"radio_2.4G",
	"WifiRadioConfig":	[{
			"WifiRadioSetup":	{
				"RadioIndex":	0,
				"VapMap":	[{
						"VapName":	"private_ssid_2g",
						"VapIndex":	0
					}, {
						"VapName":	"mesh_backhaul_2g",
						"VapIndex":	12
					}, {
						"VapName":	"iot_ssid_2g",
						"VapIndex":	2
					}]
			},
			"RadioName":	"radio1",
			"Enabled":	true,
			"FreqBand":	1,
			"AutoChannelEnabled":	true,
			"Channel":	6,
			"NumSecondaryChannels":	0,
			"SecondaryChannelsList":	" ",
			"ChannelWidth":	1,
			"HwMode":	268,
			"CsaBeaconCount":	100,
			"Country":	"US",
			"RegDomain":	0,
			"OperatingEnvironment":	"I",
			"DFSEnable":	false,
			"DfsEnabledBootup":	false,
			"ChannelAvailability":	"1:1,2:1,3:1,4:1,5:1,6:1,7:1,8:1,9:1,10:1,11:1,12:1,13:1,14:1",
			"radarInfo":	"last_channel:0,num_detected:0,time:0",
			"DcsEnabled":	false,
			"DtimPeriod":	1,
			"OperatingClass":	81,
			"BasicDataTransmitRates":	656,
			"OperationalDataTransmitRates":	8112,
			"FragmentationThreshold":	2346,
			"GuardInterval":	16,
			"TransmitPower":	100,
			"BeaconInterval":	100,
			"RtsThreshold":	2347,
			"FactoryResetSsid":	false,
			"RadioStatsMeasuringRate":	0,
			"RadioStatsMeasuringInterval":	0,
			"CtsProtection":	false,
			"ObssCoex":	true,
			"StbcEnable":	true,
			"GreenFieldEnable":	false,
			"UserControl":	0,
			"AdminControl":	0,
			"ChanUtilThreshold":	90,
			"ChanUtilSelfHealEnable":	false,
			"EcoPowerDown":	false,
			"Tscan":	0,
			"Nscan":	0,
			"Tidle":	0,
			"DfsTimer":	30,
			"RadarDetected":	" ",
			"Amsdu_Tid":	"0,0,0,0,0,0,0,0",
			"NumberOfOpClass":	3,
			"OperatingClasses":	[{
					"NumberOfNonOperChan":	2,
					"Class":	81,
					"MaxTxPower":	-30,
					"NonOperable":	[12, 13]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	83,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	2,
					"Class":	84,
					"MaxTxPower":	-30,
					"NonOperable":	[12, 13]
				}],
			"CurrentOperatingClasses":	[{
					"Class":	81,
					"Channel":	6
				}]
		}]
}
find_em_for_msg_type:1549: Received em_msg_type_channel_sel_req, found existing radio:02:02:20:ec:07:93
handle_channel_sel_req:1682 Received channel selection request
refresh_onewifi_subdoc:993 Radio subdoc send successfull
analyze_channel_sel_req:414 No of opclass=1 tx=0
refresh_onewifi_subdoc:976 Radio subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"radio_5G",
	"WifiRadioConfig":	[{
			"WifiRadioSetup":	{
				"RadioIndex":	1,
				"VapMap":	[{
						"VapName":	"private_ssid_5g",
						"VapIndex":	1
					}, {
						"VapName":	"mesh_backhaul_5g",
						"VapIndex":	13
					}, {
						"VapName":	"iot_ssid_5g",
						"VapIndex":	3
					}, {
						"VapName":	"mesh_sta_5g",
						"VapIndex":	15
					}]
			},
			"RadioName":	"radio2",
			"Enabled":	true,
			"FreqBand":	2,
			"AutoChannelEnabled":	true,
			"Channel":	36,
			"NumSecondaryChannels":	0,
			"SecondaryChannelsList":	" ",
			"ChannelWidth":	4,
			"HwMode":	425,
			"CsaBeaconCount":	100,
			"Country":	"US",
			"RegDomain":	0,
			"OperatingEnvironment":	"I",
			"DFSEnable":	false,
			"DfsEnabledBootup":	false,
			"ChannelAvailability":	"36:1,40:1,44:1,48:1,52:2,56:2,60:2,64:2,100:2,104:2,108:2,112:2,116:2,120:2,124:2,128:2,132:2,136:2,140:2,144:2,149:1,153:1,157:1,161:1,165:1,169:1,173:1,177:1",
			"radarInfo":	"last_channel:0,num_detected:0,time:0",
			"DcsEnabled":	false,
			"DtimPeriod":	1,
			"OperatingClass":	115,
			"BasicDataTransmitRates":	656,
			"OperationalDataTransmitRates":	8112,
			"FragmentationThreshold":	2346,
			"GuardInterval":	16,
			"TransmitPower":	100,
			"BeaconInterval":	100,
			"RtsThreshold":	2347,
			"FactoryResetSsid":	false,
			"RadioStatsMeasuringRate":	0,
			"RadioStatsMeasuringInterval":	0,
			"CtsProtection":	false,
			"ObssCoex":	true,
			"StbcEnable":	true,
			"GreenFieldEnable":	false,
			"UserControl":	0,
			"AdminControl":	0,
			"ChanUtilThreshold":	90,
			"ChanUtilSelfHealEnable":	false,
			"EcoPowerDown":	false,
			"Tscan":	63,
			"Nscan":	8,
			"Tidle":	5,
			"DfsTimer":	30,
			"RadarDetected":	" ",
			"Amsdu_Tid":	"0,0,0,0,0,0,0,0",
			"NumberOfOpClass":	16,
			"OperatingClasses":	[{
					"NumberOfNonOperChan":	0,
					"Class":	115,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	116,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	117,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	118,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	119,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	120,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	121,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	122,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	123,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	124,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	2,
					"Class":	125,
					"MaxTxPower":	-30,
					"NonOperable":	[169, 173]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	126,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	1,
					"Class":	127,
					"MaxTxPower":	-30,
					"NonOperable":	[169]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	128,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	129,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	130,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}],
			"CurrentOperatingClasses":	[{
					"Class":	115,
					"Channel":	36
				}]
		}]
}
refresh_onewifi_subdoc:993 Radio subdoc send successfull
onewifi_cb:1331 Found SubDocName: radio
analyze_onewifi_radio_cb:361 Radio subdoc decode success
commit_config:129 Radio 02:02:10:ec:07:92 configuration updated
commit_config:146 op class=81  already exist so updated
commit_config:146 op class=83  already exist so updated
commit_config:146 op class=84  already exist so updated
commit_config:155 op class=12  already exist so updated  ID = 1
build_candidates:454 Operating Channel Report build candidate MAC=02:02:10:ec:07:92
submitted command for orchestration
send_channel_pref_report_msg:1251: Channel Preference Report send success
process_state:1968 channel_pref_report_msg send
send_operating_channel_report_msg:895 Operating Channel Report msg send for 02:02:10:ec:07:92
process_state:1976 operating_channel_report_msg send
onewifi_cb:1331 Found SubDocName: radio
analyze_onewifi_radio_cb:361 Radio subdoc decode success
commit_config:129 Radio 02:02:20:ec:07:93 configuration updated
commit_config:146 op class=115  already exist so updated
commit_config:146 op class=116  already exist so updated
commit_config:146 op class=117  already exist so updated
commit_config:146 op class=118  already exist so updated
commit_config:146 op class=119  already exist so updated
commit_config:146 op class=120  already exist so updated
commit_config:146 op class=121  already exist so updated
commit_config:146 op class=122  already exist so updated
commit_config:146 op class=123  already exist so updated
commit_config:146 op class=124  already exist so updated
commit_config:146 op class=125  already exist so updated
commit_config:146 op class=126  already exist so updated
commit_config:146 op class=127  already exist so updated
commit_config:146 op class=128  already exist so updated
commit_config:146 op class=129  already exist so updated
commit_config:146 op class=130  already exist so updated
commit_config:155 op class=1  already exist so updated  ID = 1
build_candidates:454 Operating Channel Report build candidate MAC=02:02:20:ec:07:93
submitted command for orchestration
send_operating_channel_report_msg:895 Operating Channel Report msg send for 02:02:20:ec:07:93
process_state:1976 operating_channel_report_msg send
find_em_for_msg_type:1549: Received em_msg_type_channel_sel_req, found existing radio:02:02:30:ec:07:94
handle_channel_sel_req:1682 Received channel selection request
analyze_channel_sel_req:414 No of opclass=1 tx=0
refresh_onewifi_subdoc:976 Radio subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"radio_6G",
	"WifiRadioConfig":	[{
			"WifiRadioSetup":	{
				"RadioIndex":	2,
				"VapMap":	[{
						"VapName":	"private_ssid_6g",
						"VapIndex":	16
					}]
			},
			"RadioName":	"radio3",
			"Enabled":	true,
			"FreqBand":	16,
			"AutoChannelEnabled":	true,
			"Channel":	1,
			"NumSecondaryChannels":	0,
			"SecondaryChannelsList":	" ",
			"ChannelWidth":	8,
			"HwMode":	384,
			"CsaBeaconCount":	100,
			"Country":	"US",
			"RegDomain":	0,
			"OperatingEnvironment":	"I",
			"DFSEnable":	false,
			"DfsEnabledBootup":	false,
			"ChannelAvailability":	"1:1,5:1,9:1,13:1,17:1,21:1,25:1,29:1,33:1,37:1,41:1,45:1,49:1,53:1,57:1,61:1,65:1,69:1,73:1,77:1,81:1,85:1,89:1,93:1,97:1,101:1,105:1,109:1,113:1,117:1,121:1,125:1,129:1,133:1,137:1,141:1,145:1,149:1,153:1,157:1,161:1,165:1,169:1,173:1,177:1,181:1,185:1,189:1,193:1,197:1,201:1,205:1,209:1,213:1,217:1,221:1,225:1,229:1,233:1",
			"radarInfo":	"last_channel:0,num_detected:0,time:0",
			"DcsEnabled":	false,
			"DtimPeriod":	1,
			"OperatingClass":	135,
			"BasicDataTransmitRates":	656,
			"OperationalDataTransmitRates":	8112,
			"FragmentationThreshold":	2346,
			"GuardInterval":	16,
			"TransmitPower":	100,
			"BeaconInterval":	100,
			"RtsThreshold":	2347,
			"FactoryResetSsid":	false,
			"RadioStatsMeasuringRate":	0,
			"RadioStatsMeasuringInterval":	0,
			"CtsProtection":	false,
			"ObssCoex":	true,
			"StbcEnable":	true,
			"GreenFieldEnable":	false,
			"UserControl":	0,
			"AdminControl":	0,
			"ChanUtilThreshold":	90,
			"ChanUtilSelfHealEnable":	false,
			"EcoPowerDown":	false,
			"Tscan":	0,
			"Nscan":	0,
			"Tidle":	0,
			"DfsTimer":	30,
			"RadarDetected":	" ",
			"Amsdu_Tid":	"0,0,0,0,0,0,0,0",
			"NumberOfOpClass":	6,
			"OperatingClasses":	[{
					"NumberOfNonOperChan":	0,
					"Class":	131,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	132,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	133,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	1,
					"Class":	134,
					"MaxTxPower":	23,
					"NonOperable":	[169]
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	135,
					"MaxTxPower":	-30,
					"NonOperable":	"[]"
				}, {
					"NumberOfNonOperChan":	0,
					"Class":	136,
					"MaxTxPower":	23,
					"NonOperable":	"[]"
				}],
			"CurrentOperatingClasses":	[{
					"Class":	135,
					"Channel":	1
				}]
		}]
}
refresh_onewifi_subdoc:993 Radio subdoc send successfull
translate_and_decode_onewifi_subdoc:928: Enter
translate_associated_clients_to_easymesh_sta_info:616: client_state: 0
get_sta_info:2428: key=02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
get_sta_info:2431: sta: 02:02:23:fe:44:5f not found in Assoc Map
put_sta_info:2467: Put sta key=02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
translate_and_decode_onewifi_subdoc:948 Assoc clients decode success
build_candidates:376 pcmd radio mac=02:02:10:ec:07:92
get_sta_info:2428: key=02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
get_sta_info:2431: sta: 02:02:23:fe:44:5f not found in Consolidated Map
Consolidated map new addition with key: 02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
build_candidates:376 pcmd radio mac=02:02:20:ec:07:93
get_sta_info:2428: key=02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
get_sta_info:2435: sta: 02:02:23:fe:44:5f found in Consolidated Map
Consolidated Map, sta exists; updating with key: 02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
build_candidates:376 pcmd radio mac=02:02:30:ec:07:94
get_sta_info:2428: key=02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
get_sta_info:2435: sta: 02:02:23:fe:44:5f found in Consolidated Map
Consolidated Map, sta exists; updating with key: 02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
analyze_sta_list submit complete
handle_policy_cfg_req:486 Recvd policy for radio 02:02:10:ec:07:92
refresh_onewifi_subdoc:976 Policy subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"Easymesh Config",
	"WifiEMConfig":	[{
			"Policy":	{
				"AP Metrics Reporting Policy":	{
					"Interval":	60,
					"Managed Client Marker":	""
				},
				"Local Steering Disallowed Policy":	{
					"Disallowed STA":	[]
				},
				"BTM Steering Disallowed Policy":	{
					"Disallowed STA":	[]
				},
				"Backhaul BSS Configuration Policy":	{
					"BSSID":	"",
					"Profile-1 bSTA Disallowed":	false,
					"Profile-2 bSTA Disallowed":	true
				},
				"Channel Scan Reporting Policy":	{
					"Report Independent Channel Scans":	0
				},
				"Radio Specific Metrics Policy":	[{
						"ID":	"02:02:10:ec:07:92",
						"STA RCPI Threshold":	120,
						"STA RCPI Hysteresis":	5,
						"AP Utilization Threshold":	60,
						"STA Traffic Stats":	true,
						"STA Link Metrics":	true,
						"STA Status":	false
					}]
			}
		}]
}
refresh_onewifi_subdoc:993 Policy subdoc send successfull
handle_policy_cfg_req:486 Recvd policy for radio 02:02:20:ec:07:93
refresh_onewifi_subdoc:976 Policy subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"Easymesh Config",
	"WifiEMConfig":	[{
			"Policy":	{
				"AP Metrics Reporting Policy":	{
					"Interval":	60,
					"Managed Client Marker":	""
				},
				"Local Steering Disallowed Policy":	{
					"Disallowed STA":	[]
				},
				"BTM Steering Disallowed Policy":	{
					"Disallowed STA":	[]
				},
				"Backhaul BSS Configuration Policy":	{
					"BSSID":	"",
					"Profile-1 bSTA Disallowed":	false,
					"Profile-2 bSTA Disallowed":	true
				},
				"Channel Scan Reporting Policy":	{
					"Report Independent Channel Scans":	0
				},
				"Radio Specific Metrics Policy":	[{
						"ID":	"02:02:20:ec:07:93",
						"STA RCPI Threshold":	120,
						"STA RCPI Hysteresis":	5,
						"AP Utilization Threshold":	60,
						"STA Traffic Stats":	true,
						"STA Link Metrics":	true,
						"STA Status":	false
					}]
			}
		}]
}
refresh_onewifi_subdoc:993 Policy subdoc send successfull
send_topology_notification_by_client:165 Create topology notification msg successful, len:50
send_topology_notification_by_client:178: Topology notification Send Successful
onewifi_cb:1331 Found SubDocName: radio
analyze_onewifi_radio_cb:361 Radio subdoc decode success
commit_config:129 Radio 02:02:30:ec:07:94 configuration updated
commit_config:146 op class=131  already exist so updated
commit_config:146 op class=132  already exist so updated
commit_config:146 op class=133  already exist so updated
commit_config:146 op class=134  already exist so updated
commit_config:146 op class=135  already exist so updated
commit_config:146 op class=136  already exist so updated
commit_config:155 op class=134  already exist so updated  ID = 1
build_candidates:454 Operating Channel Report build candidate MAC=02:02:30:ec:07:94
submitted command for orchestration
send_operating_channel_report_msg:895 Operating Channel Report msg send for 02:02:30:ec:07:94
process_state:1976 operating_channel_report_msg send
handle_channel_scan_params:669: Scan Parameters received
[onewifi_em_agent] 09/16/2025 - 05:38:42.065302 :em_agent.cpp:693: INFO: Radio: 02:02:10:ec:07:92 Num of Op Classes: 3
Op Class: 81 Channels: 3 6 9
Op Class: 115 Channels: 36 40 44 48 149 153 157 161 165
Op Class: 135 Channels: 1
[onewifi_em_agent] 09/16/2025 - 05:38:42.065376 :em_agent.cpp:728: INFO: Sending channel scan request to: Device.WiFi.EM.ChannelScanRequest
[onewifi_em_agent] 09/16/2025 - 05:38:42.066739 :em_agent.cpp:734: INFO: Sent channel scan request to bus

handle_channel_scan_params:669: Scan Parameters received
[onewifi_em_agent] 09/16/2025 - 05:38:42.066790 :em_agent.cpp:693: INFO: Radio: 02:02:20:ec:07:93 Num of Op Classes: 3
Op Class: 81 Channels: 3 6 9
Op Class: 115 Channels: 36 40 44 48 149 153 157 161 165
Op Class: 135 Channels: 1
[onewifi_em_agent] 09/16/2025 - 05:38:42.066810 :em_agent.cpp:728: INFO: Sending channel scan request to: Device.WiFi.EM.ChannelScanRequest
[onewifi_em_agent] 09/16/2025 - 05:38:42.067638 :em_agent.cpp:734: INFO: Sent channel scan request to bus

handle_policy_cfg_req:486 Recvd policy for radio 02:02:30:ec:07:94
refresh_onewifi_subdoc:976 Policy subdoc encode success {
	"Version":	"1.0",
	"SubDocName":	"Easymesh Config",
	"WifiEMConfig":	[{
			"Policy":	{
				"AP Metrics Reporting Policy":	{
					"Interval":	60,
					"Managed Client Marker":	""
				},
				"Local Steering Disallowed Policy":	{
					"Disallowed STA":	[]
				},
				"BTM Steering Disallowed Policy":	{
					"Disallowed STA":	[]
				},
				"Backhaul BSS Configuration Policy":	{
					"BSSID":	"",
					"Profile-1 bSTA Disallowed":	false,
					"Profile-2 bSTA Disallowed":	true
				},
				"Channel Scan Reporting Policy":	{
					"Report Independent Channel Scans":	0
				},
				"Radio Specific Metrics Policy":	[{
						"ID":	"02:02:30:ec:07:94",
						"STA RCPI Threshold":	120,
						"STA RCPI Hysteresis":	5,
						"AP Utilization Threshold":	60,
						"STA Traffic Stats":	true,
						"STA Link Metrics":	true,
						"STA Status":	false
					}]
			}
		}]
}
refresh_onewifi_subdoc:993 Policy subdoc send successfull
handle_channel_scan_params:669: Scan Parameters received
[onewifi_em_agent] 09/16/2025 - 05:38:45.077228 :em_agent.cpp:693: INFO: Radio: 02:02:30:ec:07:94 Num of Op Classes: 3
Op Class: 81 Channels: 3 6 9
Op Class: 115 Channels: 36 40 44 48 149 153 157 161 165
Op Class: 135 Channels: 1
[onewifi_em_agent] 09/16/2025 - 05:38:45.077289 :em_agent.cpp:728: INFO: Sending channel scan request to: Device.WiFi.EM.ChannelScanRequest
[onewifi_em_agent] 09/16/2025 - 05:38:45.078301 :em_agent.cpp:734: INFO: Sent channel scan request to bus

find_em_for_msg_type:1578: Received client cap query: found radio for bss:02:02:21:ec:07:97
[onewifi_em_agent] 09/16/2025 - 05:38:47.065576 :em_capability.cpp:383: INFO: send_client_cap_report_msg for controller mac address:02:01:00:ec:07:9e
send_client_cap_report_msg:453: Client Capablity report Send Successful for sta:02:02:23:fe:44:5f
find_em_for_msg_type:1578: Received client cap query: found radio for bss:02:02:21:ec:07:97
[onewifi_em_agent] 09/16/2025 - 05:38:47.067133 :em_capability.cpp:383: INFO: send_client_cap_report_msg for controller mac address:02:01:00:ec:07:9e
send_client_cap_report_msg:453: Client Capablity report Send Successful for sta:02:02:23:fe:44:5f
find_em_for_msg_type:1578: Received client cap query: found radio for bss:02:02:21:ec:07:97
[onewifi_em_agent] 09/16/2025 - 05:38:47.077407 :em_capability.cpp:383: INFO: send_client_cap_report_msg for controller mac address:02:01:00:ec:07:9e
send_client_cap_report_msg:453: Client Capablity report Send Successful for sta:02:02:23:fe:44:5f
find_em_for_msg_type:1578: Received client cap query: found radio for bss:02:02:21:ec:07:97
[onewifi_em_agent] 09/16/2025 - 05:38:48.065597 :em_capability.cpp:383: INFO: send_client_cap_report_msg for controller mac address:02:01:00:ec:07:9e
send_client_cap_report_msg:453: Client Capablity report Send Successful for sta:02:02:23:fe:44:5f
find_em_for_msg_type:1578: Received client cap query: found radio for bss:02:02:21:ec:07:97
[onewifi_em_agent] 09/16/2025 - 05:38:48.077529 :em_capability.cpp:383: INFO: send_client_cap_report_msg for controller mac address:02:01:00:ec:07:9e
send_client_cap_report_msg:453: Client Capablity report Send Successful for sta:02:02:23:fe:44:5f
analyze_ap_metrics_report:868: Enter
translate_and_decode_onewifi_subdoc:928: Enter
translate_and_decode_onewifi_subdoc:948 AP Metrics Report decode success
Submitted AP Metrics report cmd for orch
is_cmd_type_renew_in_progress:268: Command of type: 43 actively executing
analyze_ap_metrics_report:868: Enter
translate_and_decode_onewifi_subdoc:928: Enter
get_sta_info:2428: key=02:02:23:fe:44:5f@02:02:21:ec:07:97@02:02:20:ec:07:93
get_sta_info:2435: sta: 02:02:23:fe:44:5f found in Consolidated Map
translate_and_decode_onewifi_subdoc:948 AP Metrics Report decode success
Submitted AP Metrics report cmd for orch
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:10:ec:07:92
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:11:ec:07:95
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:12:ec:07:96
send_ap_metrics_response:989: AP Metrics Response send success
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:20:ec:07:93
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:21:ec:07:97
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:22:ec:07:98
create_ap_metrics_tlv:1264 Creating ap response for bssid: 00:00:00:00:00:00
Failed TLV [1]: 17.2.73 of Wi-Fi Easy Mesh 5.0
send_ap_metrics_response:980: AP Metrics Response validation failed for
                                                                        �
send_ap_metrics_response:989: AP Metrics Response send success
analyze_ap_metrics_report:868: Enter
translate_and_decode_onewifi_subdoc:928: Enter
translate_and_decode_onewifi_subdoc:948 AP Metrics Report decode success
Submitted AP Metrics report cmd for orch
create_ap_metrics_tlv:1264 Creating ap response for bssid: 02:02:30:ec:07:94
send_ap_metrics_response:989: AP Metrics Response send success
find_em_for_msg_type:1459: Found existing AL MAC:02:01:00:ec:07:ae_al
analyze_autoconfig_renew:191 Renew Radiomac = 02:02:10:ec:07:92
build_candidates:365 Renew 02:02:10:ec:07:92 added
find_em_for_msg_type:1459: Found existing AL MAC:02:01:00:ec:07:ae_al
is_cmd_type_renew_in_progress:268: Command of type: 21 actively executing
analyze_autoconfig_renew:191 Renew Radiomac = 02:02:20:ec:07:93
build_candidates:365 Renew 02:02:20:ec:07:93 added
find_em_for_msg_type:1459: Found existing AL MAC:02:01:00:ec:07:ae_al
is_cmd_type_renew_in_progress:268: Command of type: 21 actively executing
analyze_autoconfig_renew:191 Renew Radiomac = 02:02:30:ec:07:94
build_candidates:365 Renew 02:02:30:ec:07:94 added
Op Class 0: 81, max_tx_eirp: -30, channels.num: 2
 cap->op_classes[0].op_class: 81, cap->op_classes[0].max_tx_eirp 226,	cap->op_classes[0].channels.num 2
Op Class 1: 83, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[1].op_class: 12, cap->op_classes[1].max_tx_eirp 13,	cap->op_classes[1].channels.num 83
Op Class 2: 84, max_tx_eirp: -30, channels.num: 2
 cap->op_classes[2].op_class: 226, cap->op_classes[2].max_tx_eirp 0,	cap->op_classes[2].channels.num 84
[onewifi_em_agent] 09/16/2025 - 05:39:49.203325 :em.cpp:951: INFO: Created AP Radio Basic Cap TLV for Radio:02:02:10:ec:07:92, num_bss:3, op_class_num:3, len:21
[onewifi_em_agent] 09/16/2025 - 05:39:49.203388 :em_configuration.cpp:2353: INFO: WPS Auth Flags: 0x0000
handle_state_autoconfig_renew:5228: autoconfig wsc m1 send success
find_em_for_msg_type:1459: Found existing AL MAC:02:01:00:ec:07:ae_al
find_em_for_msg_type:1471: Found matching band0 but incorrect em state 4
find_em_for_msg_type:1459: Found existing AL MAC:02:01:00:ec:07:ae_al
is_cmd_type_renew_in_progress:268: Command of type: 21 actively executing
is_cmd_type_renew_in_progress:278: Command of type: 21 actively executing for 02:02:20:ec:07:93
handle_autoconfig_renew in progress
find_em_for_msg_type:1459: Found existing AL MAC:02:01:00:ec:07:ae_al
is_cmd_type_renew_in_progress:268: Command of type: 21 actively executing
is_cmd_type_renew_in_progress:278: Command of type: 21 actively executing for 02:02:30:ec:07:94
handle_autoconfig_renew in progress
Op Class 4: 115, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[4].op_class: 0, cap->op_classes[4].max_tx_eirp 0,	cap->op_classes[4].channels.num 0
Op Class 5: 116, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[5].op_class: 32, cap->op_classes[5].max_tx_eirp 47,	cap->op_classes[5].channels.num 230
Op Class 6: 117, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[6].op_class: 145, cap->op_classes[6].max_tx_eirp 127,	cap->op_classes[6].channels.num 0
Op Class 7: 118, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[7].op_class: 0, cap->op_classes[7].max_tx_eirp 0,	cap->op_classes[7].channels.num 116
Op Class 8: 119, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[8].op_class: 7, cap->op_classes[8].max_tx_eirp 155,	cap->op_classes[8].channels.num 149
Op Class 9: 120, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[9].op_class: 127, cap->op_classes[9].max_tx_eirp 0,	cap->op_classes[9].channels.num 0
Op Class 10: 121, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[10].op_class: 0, cap->op_classes[10].max_tx_eirp 48,	cap->op_classes[10].channels.num 0
Op Class 11: 122, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[11].op_class: 0, cap->op_classes[11].max_tx_eirp 136,	cap->op_classes[11].channels.num 127
Op Class 12: 123, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[12].op_class: 0, cap->op_classes[12].max_tx_eirp 0,	cap->op_classes[12].channels.num 0
Op Class 13: 124, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[13].op_class: 192, cap->op_classes[13].max_tx_eirp 103,	cap->op_classes[13].channels.num 230
Op Class 14: 125, max_tx_eirp: -30, channels.num: 2
 cap->op_classes[14].op_class: 145, cap->op_classes[14].max_tx_eirp 127,	cap->op_classes[14].channels.num 0
Op Class 15: 126, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[15].op_class: 0, cap->op_classes[15].max_tx_eirp 0,	cap->op_classes[15].channels.num 46
Op Class 16: 127, max_tx_eirp: -30, channels.num: 1
 cap->op_classes[16].op_class: 78, cap->op_classes[16].max_tx_eirp 6,	cap->op_classes[16].channels.num 0
Op Class 17: 128, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[17].op_class: 0, cap->op_classes[17].max_tx_eirp 0,	cap->op_classes[17].channels.num 0
Op Class 18: 129, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[18].op_class: 0, cap->op_classes[18].max_tx_eirp 200,	cap->op_classes[18].channels.num 0
Op Class 19: 130, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[19].op_class: 0, cap->op_classes[19].max_tx_eirp 0,	cap->op_classes[19].channels.num 0
[onewifi_em_agent] 09/16/2025 - 05:39:50.215395 :em.cpp:951: INFO: Created AP Radio Basic Cap TLV for Radio:02:02:20:ec:07:93, num_bss:4, op_class_num:16, len:59
[onewifi_em_agent] 09/16/2025 - 05:39:50.215476 :em_configuration.cpp:2353: INFO: WPS Auth Flags: 0x0000
handle_state_autoconfig_renew:5228: autoconfig wsc m1 send success
update_scan_results:2791 creating new scan result
analyze_scan_result:782 scanner mac: 02:02:30:ec:07:94 - analyze_scan_result subdoc decode success
Op Class 21: 131, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[21].op_class: 0, cap->op_classes[21].max_tx_eirp 16,	cap->op_classes[21].channels.num 172
Op Class 22: 132, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[22].op_class: 149, cap->op_classes[22].max_tx_eirp 127,	cap->op_classes[22].channels.num 0
Op Class 23: 133, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[23].op_class: 0, cap->op_classes[23].max_tx_eirp 0,	cap->op_classes[23].channels.num 136
Op Class 24: 134, max_tx_eirp: 23, channels.num: 1
 cap->op_classes[24].op_class: 104, cap->op_classes[24].max_tx_eirp 101,	cap->op_classes[24].channels.num 145
Op Class 25: 135, max_tx_eirp: -30, channels.num: 0
 cap->op_classes[25].op_class: 127, cap->op_classes[25].max_tx_eirp 0,	cap->op_classes[25].channels.num 0
Op Class 26: 136, max_tx_eirp: 23, channels.num: 0
 cap->op_classes[26].op_class: 0, cap->op_classes[26].max_tx_eirp 24,	cap->op_classes[26].channels.num 0
[onewifi_em_agent] 09/16/2025 - 05:39:51.226856 :em.cpp:951: INFO: Created AP Radio Basic Cap TLV for Radio:02:02:30:ec:07:94, num_bss:1, op_class_num:6, len:27
[onewifi_em_agent] 09/16/2025 - 05:39:51.226911 :em_configuration.cpp:2353: INFO: WPS Auth Flags: 0x0000

iw dev sample o/p from ctrl and Remote Agent

iw_dev_ctrl
root@Filogic-GW:~# iw dev
phy#0
	Interface wifi1.1.sta1
		ifindex 31
		wdev 0xa
		addr 02:02:21:ec:07:97
		type AP/VLAN
		channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		4addr: on
		Radios: 0 1 2
	Interface mld0
		ifindex 30
		wdev 0x9
		addr 02:02:30:ec:07:95
		ssid private_ssid
		type AP
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		MLD with links:
		 - link ID  1 link addr 02:02:20:ec:07:93
		   channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		   txpower 23.00 dBm
		Radios: 0 1 2
	Interface wifi2
		ifindex 29
		wdev 0x8
		addr 02:02:30:ec:07:94
		ssid private_ssid
		type AP
		channel 1 (5955 MHz), width: 160 MHz, center1: 6025 MHz
		txpower 12.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi1.3
		ifindex 28
		wdev 0x7
		addr 02:02:23:ec:07:99
		type managed
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		4addr: on
		Radios: 0 1 2
	Interface wifi1.2
		ifindex 27
		wdev 0x6
		addr 02:02:22:ec:07:98
		ssid iot_ssid
		type AP
		channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		txpower 23.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi1.1
		ifindex 26
		wdev 0x5
		addr 02:02:21:ec:07:97
		ssid mesh_backhaul
		type AP
		channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		txpower 23.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi1
		ifindex 25
		wdev 0x4
		addr 02:02:20:ec:07:93
		type AP
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi0.2
		ifindex 24
		wdev 0x3
		addr 02:02:12:ec:07:96
		ssid iot_ssid
		type AP
		channel 6 (2437 MHz), width: 20 MHz, center1: 2437 MHz
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi0.1
		ifindex 23
		wdev 0x2
		addr 02:02:11:ec:07:95
		ssid mesh_backhaul
		type AP
		channel 6 (2437 MHz), width: 20 MHz, center1: 2437 MHz
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi0
		ifindex 22
		wdev 0x1
		addr 02:02:10:ec:07:92
		ssid private_ssid
		type AP
		channel 6 (2437 MHz), width: 20 MHz, center1: 2437 MHz
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
root@Filogic-GW:~#
iw_dev_remote_agent
root@Filogic-GW:~# iw dev
phy#0
	Interface mld0
		ifindex 22
		wdev 0x9
		addr 02:02:30:fe:44:5b
		ssid private_ssid
		type AP
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		MLD with links:
		 - link ID  1 link addr 02:02:20:fe:44:59
		   channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		   txpower 23.00 dBm
		Radios: 0 1 2
	Interface wifi2
		ifindex 21
		wdev 0x8
		addr 02:02:30:fe:44:5a
		ssid private_ssid
		type AP
		channel 5 (5975 MHz), width: 160 MHz, center1: 6025 MHz
		txpower 12.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi1.3
		ifindex 20
		wdev 0x7
		addr 02:02:23:fe:44:5f
		ssid mesh_backhaul
		type managed
		channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		txpower 23.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		4addr: on
		Radios: 0 1 2
	Interface wifi1.2
		ifindex 19
		wdev 0x6
		addr 02:02:22:fe:44:5e
		ssid iot_ssid
		type AP
		channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		txpower 23.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi1.1
		ifindex 18
		wdev 0x5
		addr 02:02:21:fe:44:5d
		ssid mesh_backhaul
		type AP
		channel 36 (5180 MHz), width: 80 MHz, center1: 5210 MHz
		txpower 23.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi1
		ifindex 17
		wdev 0x4
		addr 02:02:20:fe:44:59
		type AP
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi0.2
		ifindex 16
		wdev 0x3
		addr 02:02:12:fe:44:5c
		ssid iot_ssid
		type AP
		channel 6 (2437 MHz), width: 20 MHz, center1: 2437 MHz
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi0.1
		ifindex 15
		wdev 0x2
		addr 02:02:11:fe:44:5b
		ssid mesh_backhaul
		type AP
		channel 6 (2437 MHz), width: 20 MHz, center1: 2437 MHz
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
	Interface wifi0
		ifindex 14
		wdev 0x1
		addr 02:02:10:fe:44:58
		ssid private_ssid
		type AP
		channel 6 (2437 MHz), width: 20 MHz, center1: 2437 MHz
		txpower 27.00 dBm
		multicast TXQ:
			qsz-byt	qsz-pkt	flows	drops	marks	overlmt	hashcol	tx-bytes	tx-packets
			0	0	0	0	0	0	0	0		0
		Radios: 0 1 2
root@Filogic-GW:~#


Debugging tips and reference success logs

Create following file to get onewifi debug and info logs and check corresponding files in /tmp folder.

touch /nvram/wifiHalDbg
touch /nvram/wifiCtrlDbg
touch /nvram/wifiMgrDbg
touch /nvram/wifiLibhostapDbg
touch /nvram/wifiWebConfigDbg
touch /nvram/wifiPasspointDbg
touch /nvram/wifiDMCLI
touch /nvram/wifiDbDbg
touch /nvram/wifiPsm
touch /nvram/wifiHalStatsDbg

EasyMesh AP profile

Next phase

  • Optimizing mariaDB - Target to keep size < 10 MB

Platform agnostic c++ coding

State machine(WIP)

Child pages

    EasyMesh(unified-wifi-mesh) Build instructions and Validation steps - Kirkstone






  • No labels

1 Comment

  1. Chandrakanth Pokuru

    Jul 22, 2025

    logic-GW:/mnt/chandra/maria# mysql -u root -p -e "CREATE USER 'bpi'@'localhost' IDENTIFIED BY 'root';"
    Enter password:
    root@Filogic-GW:/mnt/chandra/maria#
    root@Filogic-GW:/mnt/chandra/maria# mysql -u root -p -e "ALTER USER 'bpi'@'localhost' IDENTIFIED BY 'root';"
    Enter password:
    root@Filogic-GW:/mnt/chandra/maria# mysql -u root -p -e "GRANT ALL PRIVILEGES ON *.* TO 'bpi'@'localhost' IDENTIFIED BY 'root';"
    Enter password:
    root@Filogic-GW:/mnt/chandra/maria# mysql -u root -p -e "FLUSH PRIVILEGES;"
    Enter password:
    root@Filogic-GW:/mnt/chandra/maria# mysql -u root -p -e "SELECT User, Host, plugin FROM mysql.user WHERE User = 'bpi';"
    Enter password:
    +------+-----------+-----------------------+
    | User | Host   | plugin        |
    +------+-----------+-----------------------+
    | bpi | localhost | mysql_native_password |
    +------+-----------+-----------------------+
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "SELECT USER(), CONNECTION_ID();"
    Enter password:
    ERROR 1045 (28000): Access denied for user 'bpi'@'localhost' (using password: NO)
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "SELECT USER(), CONNECTION_ID();"
    Enter password:
    +---------------+-----------------+
    | USER()    | CONNECTION_ID() |
    +---------------+-----------------+
    | bpi@localhost |       17 |
    +---------------+-----------------+
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "CREATE DATABASE OneWifiMesh;"
    Enter password:
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "SHOW DATABASES;"
    Enter password:
    ERROR 1045 (28000): Access denied for user 'bpi'@'localhost' (using password: NO)
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "SHOW DATABASES;"
    Enter password:
    +--------------------+
    | Database      |
    +--------------------+
    | OneWifiMesh    |
    | ecommerce_db    |
    | information_schema |
    | my_test_db     |
    | mysql       |
    | performance_schema |
    | sys        |
    | test        |
    +--------------------+
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "USE OneWifiMesh; SHOW TABLES; SELECT DATABASE();"
    Enter password:
    +-------------+
    | DATABASE() |
    +-------------+
    | OneWifiMesh |
    +-------------+
    root@Filogic-GW:/mnt/chandra/maria#
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "SHOW DATABASES;"
    Enter password:
    +--------------------+
    | Database      |
    +--------------------+
    | OneWifiMesh    |
    | ecommerce_db    |
    | information_schema |
    | my_test_db     |
    | mysql       |
    | performance_schema |
    | sys        |
    | test        |
    +--------------------+
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p OneWifiMesh -e "SELECT DATABASE(); SHOW TABLES;"
    Enter password:
    ERROR 1045 (28000): Access denied for user 'bpi'@'localhost' (using password: NO)
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p OneWifiMesh -e "SELECT DATABASE(); SHOW TABLES;"
    Enter password:
    +-------------+
    | DATABASE() |
    +-------------+
    | OneWifiMesh |
    +-------------+
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -p -e "SHOW GRANTS FOR 'bpi'@'localhost';"
    Enter password:
    +---------------------------------------------------------------------------------------------------------------------+
    | Grants for bpi@localhost                                              |
    +---------------------------------------------------------------------------------------------------------------------+
    | GRANT ALL PRIVILEGES ON *.* TO `bpi`@`localhost` IDENTIFIED BY PASSWORD '*81F5E21E35407D884A6CD4A731AEBFB6AF209E1B' |
    +---------------------------------------------------------------------------------------------------------------------+
    root@Filogic-GW:/mnt/chandra/maria#

    --------to bypass password
    6:44Chandrakanth Pokuru
    ia#
    root@Filogic-GW:/mnt/chandra/maria# export MYSQL_PWD=root
    root@Filogic-GW:/mnt/chandra/maria#
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -e "SHOW DATABASES;"
    +--------------------+
    | Database      |
    +--------------------+
    | OneWifiMesh    |
    | ecommerce_db    |
    | information_schema |
    | my_test_db     |
    | mysql       |
    | performance_schema |
    | sys        |
    | test        |
    +--------------------+
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi -e "USE OneWifiMesh; SHOW TABLES;"
    root@Filogic-GW:/mnt/chandra/maria# mysql -u bpi OneWifiMesh -e "SELECT DATABASE(); SHOW TABLES;"
    +-------------+
    | DATABASE() |
    +-------------+
    | OneWifiMesh |
    +-------------+
    root@Filogic-GW:/mnt/chandra/maria#
    add a script file and invoke it as pre_init in controller side

DISCLAIMER: Please note that the use of the RDK Wiki is subject to its Privacy Policy & Terms of Use. In addition, this Wiki may be accessed by all RDK licensees and their contractors.
